LCD
Type
32" (31.5" viewable) Wide Color TFT Active Matrix IPS LED
Display Area
27.5" horizontal x 15.5" vertical; 31.5" diagonal
Optimum Resolution
1920x1080
Contrast Ratio
3000:1 (typ.)
Viewing Angles
178º horizontal, 178º vertical
Response Time
6.5ms (typ.)
Light Source
White-light LED/ Backlight Life: 30,000 hours (min.)
Brightness
315 cd/m2 (typ.)
Panel Surface
Anti-glare, hard-coating (7H)
VIDEO INPUT
Analog/Digital
RGB analog (0.7 / 1.0 Vp-p, 75 ohms) / DVI (TMDS, 100 ohms)
Frequency
Fh: 31.5~67.5kHz, Fv: 47~63Hz
Sync
Separate Sync
COMPATIBILITY
PC
PC compatibles (VGA up to 1920 x 1080 Non-Interlaced)
Mac®
Touch function not compatible
CONNECTOR
Analog/Digital
15-pin mini D-sub (VGA) / DVI, DisplayPort (via DVI to DP adapter)
USB
1-up, 1-down (for touch module)
Audio Input
Audio In (3.5mm mini-jack) Earphone Out (3.5mm mini-jack)
Headphone
N/A
Power
Internal power board, 3-pin plug (CEE22)
AUDIO
Speakers
2 x 10W
POWER
Voltage
AC 100–240V (universal), 50 / 60Hz
Consumption
65W (typ.) / 70W (typ.)
Eco Mode
N/A
Power Save Mode
N/A
CONTROLS
Basic
Menu, Select, Down, Up, Power
OSD
Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB, DVI), Audio Adjust (Volume, Mute), Color Adjust (sRGB, Bluish, Cool, Native, Warm, User Color [R,G,B]), Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine Tune, Sharpness, Response Time, Aspect Ratio, Eco-mode), Setup Menu (Language Select, Resolution Notice, OSD Position, OSD Timeout, OSD Background, Auto Power Off, Power Indicator), Factory Reset, Fan On/Off
DIMENSIONS (WxHxD)
Physical Without Stand
35.6" x 18.9" x 2.7"
Packaging
35.6" x 24.8" x 7.3"
WEIGHT
Gross
42.55 Ibs / 19.8 Kg
Net With Stand
N/A
Net Without Stand
35.71 Ibs / 16.7 Kg
Tilt
N/A
Vesa Mount
400mm x 200mm
Regulations
CE, CB, UL/cUL,FCC-A, UkrSEPRO + DoC
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS
TD3240 display, power cable, VGA cable, DVI cable, DVI to DisplayPort adapter, audio cable, USB cable, Quick Start Guide, ViewSonic Wizard CD (available in some countries only)
Warranty
Three-year limited warranty on parts, labor and backlight.
Power Management
ENERGY STAR® standards
