SPECIFICATIONS

Display
Panel Size: 43"
Panel Type: TFT LCD Module with ELED Backlight
Display Area (mm): 941.184 (H) x 529.416 (V) (42.51" diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 350 nits (typ.)
Contrast Ratio: 1000:1
Response Time: 9 ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 30,000 Hours (Typ)
Surface Treatment: Anti-Glare4H hardness
Bezel: L:10.9/R:10.9/T:10.9/B:13.8 mm
Orientation: Landscape
Platform
Processor: ARM Cortex A73 + A53
RAM: 3GB DDR4
Storage: 16 GB
Touch
Type/ Tech: LGD In-cell 10 points touch
Touch Resolution: 32767 x 32767
Touch Point: Windows/Android: 10 points touch
INPUT
HDMI: 2.0 x1 (3840x2160 @60Hz)
RGB / VGA: x1
DisplayPort: x1
DVI: x1
Audio: x1 (PC audio in, 3.5mm jack)
RS232: x1
OUTPUT
Audio: x1 (Earphone out)
SPDIF: x1 (Fiber)
LAN
RJ45: x1
USB
Type A: USB2.0 Bottom x2
Type B: x1 for HDMI/DP/DVI/VGA touch
Type C: x1 (DP1.2, 60W power delivery)
SPEAKERS
10W x 2
COMPATIBILITY
RGB PC/HDMI PC: 1080p/4K @ 60Hz
HDMI: 3840x2160 @ 60Hz
DisplayPort: 3840x2160 @ 60Hz
DVI: 3840x2160 @ 30Hz
Embedded OS
Android 8.0
Bundle Software
Basic Annotation Software: myViewBoard Whiteboard for Android
Wireless Presentation: ViewBoard Cast & myViewBoard Display
Special Features
All-in-one USB port: Bottom "Smart USB" port for all channels.
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: On:120W(typ.) / Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 400 x 400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH Non-Condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 967 x 558.1 x 55.7 mm / 38.072 x 21.973 x 2.193 in. (w/o Stand); 967 x 582.8 x 207.1 mm / 38.072 x 22.943 x 8.155 in. (with Stand)
Packaging (inch / mm): 1200 x 785 x 210 mm / 47.24 x 30.91 x 8.27 in.
WEIGHT
Net (lb / kg): 17.83 kg / 39.3 lbs (w/o Stand); 18.41 kg / 40.59 lbs (with Stand)
Gross (lb / kg): 22.63 kg / 49.89 lbs
REGULATIONS
cULus, FCC, Energy Star, CEC, Mexico Energy, CE, CB, RoHS, RACH
PACKAGE CONTENTS
1. IFP4320
2. Power Cables (1.8 M)
3. Remote Control with batteries
4. Quick Start Guide
5. Stand (STND-056)
6. HDMI cable (1.0M)
7. USB Type-C Cable (1.0 M)
8. USB Touch Cable (1.0 M) (Type A – Type B)
9. RS232 Adapter (Female to Female)
