LIGHT ENGINE and DISPLAY
| DLP® Type |
1-chip DMD 0.66” UHD |
| Image resolution |
4K UHD (3840x2160 pixels): 8.3M pixels |
| Light Source and brightness(1) |
450W lamp (dimmable) - up to 5.000 Ansi Lumens (in 2D mode) |
| Lamp life expectancy(2) |
3000 hours typical in ECO mode |
| Adjustable iris |
12 apertures memorized |
| SIM2 Perfect Fit |
|
| Lens |
Super high definition pure-glass lens with telecentric optics |
| Lens resolution |
93 lines per millimeter |
INSTALLATION
| Lens Throw ratio (+/-5%) |
1.36-2.68:1 |
| Zoom & Focus |
Motorized with position encoders |
| Optical Shift |
+/-75% Vertical, +/- 30% Horizontal |
ELECTRONICS AND CONNECTIVITY
| Horizontal & vertical scan freq. |
15-91kHz/24-120Hz |
| UHD |
@ 24/25/30/50/60/70/72/75 Hz |
| HDTV |
480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p |
| PC graphic standard |
VGA, SVGA, XGA, SXGA, UXGA, WUXGA, UHD, 4K (4096x2160), 10 bit Full Channel Signal Board Video Processing |
| Color Calibration |
Live Colors Calibration software 2.0 |
INPUTS/OUTPUTS
| Digital |
1 x HDMI (v.2.0a - HDCP 2.2) |
| |
2 x HDMI (v.1.4a - HDCP 1.4) |
| |
1 x HDMI audio/video out (v.1.4a - HDCP) |
| |
1 x Display Port 1.2 |
| Analog |
Graphic RGBVH (VGA-UXGA) (D-sub 15 pin) |
| |
Component - Analog YPbPr/RGBs/RGBHV |
| Control |
2 x IR receivers |
| |
1 x wired IR receiver |
| |
1 x LAN (RJ45) |
| |
1 x RS232 (D-sub 9 pin) |
| |
1 x USB (A type for FW upgrade) |
| Miscellaneous |
2 x 12V 200mA output |
GENERAL SPECIFICATIONS
| Mains voltage range |
100-240 +/-10% (48/62 Hz) |
| Projector Weight |
32 Kg. / 70.5 lbs |
| Projector dimensions |
528 x 197 x 525 mm (20.8” x 7.7” x 20.7”) |
ACCESSORIES
| Supplied |
Installation and User Manual |
| |
AC power cords |
| |
Remote control and batteries |
| Optional |
Projector ceiling bracket |
| |
Anamorphic lens systems (fixed or motorized) |
(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in a totally dark test room, brand new lamp at full power, lamp’s native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification.
(2) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty.
