Specyfikacja:

LIGHT ENGINE

• Technology: 1 x chip DMD
• Resolution: Full HD 1920 x 1080 pixels
• Lighting system: SUPER PureLED technology
• 3D(*) Features:
• SIM2 DynamicBlack™ Technology enhanced solution (digital):
• Contrast ratio (Full ON/OFF): >30,000:1 with DynamicBlack™
• Brightness: 1,500 lumens (the equivalent of 2,200 lumens(**) of lamp-based projectors)
• Expected LED lifetime: 20,000 hours

INSTALLATION

• Lens Throw ratio NERO 3 PLUS: 1.51-2.88:1 (+/-5%)
• Lens Throw ratio NERO 3 PLUS ST (short throw zoom lens): 1.23-1.5:1 (+/-5%)
• Lens shift: V +/-60% /, H +/-10%
• Digital keystone adjustment: Vertical and Horizontal
• Picture size (inches diagonal): 65-200
• Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox, panoramic, pixel to pixel + 3 custom-user adjustments

ELECTRONICS

• Horiz. & vertical scan frequency: 15-80kHz/48-144Hz;
• Color System: PAL (B,G,H,I,M,N,60); SECAM; NTSC 3.58; NTSC 4.43
• PC graphic standards: VGA, SVGA, XGA,SXGA, UXGA, WUXGA
• SDTV: 480i/p, 576i/p;
• HDTV: 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p

INPUTS/OUTPUTS

• Analog: 1 x Component - YCbCr/RGBs (RCA)
• 1 x Graphic RGBHV/YCrCb (1x D-Sub 15 pin)
• 1x S-Video
• Digital: 2 x HDMI (v.1.4 with Deep Color)
• Control: 1 x RS-232
• 1 x USB (B type socket)
• 1 x USB (Service only)
• Miscellaneous: 3D Sync Out
• 1x 12V 100mA output

GENERAL SPECIFICATIONS

• Software control: upgradable via RS-232 serial interface or USB
• Power supply: 100-240 VAC +/-10% (48/62 Hz)
• Projector weight: 12 Kg. / 26.5 lbs
• Projector dimensions (WxHxD): 365x176x502 mm (14.4”x6.9”x19.8”) - lens and feet included

ACCESSORIES

• Supplied: Installation and user manual
• AC power cords
• Backlit remote control and batteries
• Live Colors Calibration software
• Optional: SIM2 VISUS Active glasses, Emitter (optional)(*)
• SIM2 VISUS Active glasses (additional pairs)
• SIM2 Universal Ceiling Bracket

(*) A SIM2 3D emitter and glasses pack is required to initiate this feature (sold separately).

(**) Takes into account Helmholtz-Kohlrausch effect where brightness rises with color saturation. LED projectors produce richer and more saturated colors, thus appearing brighter than a lamp-based display with similar measured lumen specifications..

(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in compliance with ANSI IT7.228-1997 specification.

Due to constant product development, specifications are subject to change without notice.
