LIGHT ENGINE
| Technology |
1 x 0.95” chip DMD |
| Resolution |
Full HD 1920 x 1080 pixels |
| Lighting system |
SUPER PureLED technology |
| 3D(*) Features |
SIM2’s PureAction 2D/3D and SIM2’s PureMovie 2D technologies |
| SIM2 DynamicBlack™ Technology enhanced solution (digital) |
|
| Overlap™ Technology |
|
| Contrast ratio (Full ON/OFF) |
>100,000:1 with DynamicBlack™ |
| Brightness |
1000 lumens (the equivalent of 1,500 lumens(**) of lamp-based projectors) |
| Expected LED lifetime |
30,000 hours |
INSTALLATION
| Lens option (throw ratio) |
0.675:1 (type ST) |
| Motorized Lens shift |
Not available |
| Digital keystone adjustment |
Vertical and Horizontal |
| Aspect ratio |
4:3, 16:9 Anamorphic, LetterBox, panoramic, pixel to pixel + 3 custom-user adjustments |
ELECTRONICS
| Horiz. & vertical scan frequency |
15-80kHz/48-120Hz; |
| Color System |
PAL (B,G,H,I,M,N,60); SECAM; NTSC 3.58; NTSC 4.43 |
| PC graphic standards |
VGA, SVGA, XGA,SXGA, UXGA, WUXGA |
| SDTV |
480i/p, 576i/p; |
| HDTV |
720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p |
| Color Space selection |
HDTV - EBU - SMPTE-C - ADOBE RGB - CINEMA |
INPUTS/OUTPUTS
| Analog |
1 x Composite Video (RCA) |
| |
1 x Component - YCbCr/RGBs (RCA) |
| |
1 x Graphic RGBHV/YCrCb (1x D-Sub 15 pin) |
| Digital |
2 x HDMI (v.1.4 with Deep Color) |
| Control |
1 x RS-232 |
| |
1 x USB (B type socket) |
| Miscellaneous |
3D Sync Out |
| |
3x OUT 12V (via DC Jack) |
GENERAL SPECIFICATIONS
| Software control |
upgradable via RS-232 serial interface or USB |
| Power supply |
100-240 VAC +/-10% (48/62 Hz) |
| Power consumption |
max. 370W |
| Projector weight |
28 kg. / 61.7 lbs |
| Projector dimensions (WxHxD) |
420 x 202 x 532 mm (16.5” x 8” x 21”) |
ACCESSORIES
| Supplied |
Installation and user manual |
| |
AC power cords (2m- 6.6 ft) |
| |
Backlit remote control and batteries |
| |
EasyLED 2.0 software |
| Optional |
SIM2 VISUS Active glasses, Emitter (optional)(*) |
| |
SIM2 VISUS Active glasses (additional pairs) |
| |
SIM2 Universal Ceiling Bracket |
(*) A SIM2 3D emitter and glasses pack is required to initiate this feature (sold separately).
(**) Takes into account Helmholtz-Kohlrausch effect where brightness rises with color saturation. LED projectors produce richer and more saturated colors, thus appearing brighter than a lamp-based display with similar measured lumen specifications.
(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in compliance with ANSI IT7.228-1997 specification.
