Technical Specifications

• DLP® Type and image resolution: 1-chip DMD 0.67” UHD - 4K UHD (3840x2160 pixels): 8.3M pixels
• Dynamic Range: HDR compliant for precise natural colors
• Light Source and brightness(1): 300W lamp (dimmable) up to 2200 Ansi Lumens
• Color Wheel: 6 segments (RGBRGB)
• Lens: HIgh definition pure-glass lens optics
• Lens Throw ratio (+/-5%): 1.4-2.0:1
• Zoom & Focus: Manual
• Projection angle: 12 degrees
• Optical Shift: +/-15% Vertical
• INPUTS/OUTPUTS: 2x HDMI (v.2.0a - HDCP 2.2)
• 1x HDMI-MHL (v.2.0a - HDCP 2.2)
• 1x USB (A type - power)
• 1x mini USB (B type for FW upgrade)
• 1 x RS232 (D-sub 9 pin)
• 2x IR receivers
• 1x wired IR receiver
• 1x Audio IN (mini-jack)
• 1x Audio OUT (mini-jack)
• Vertical scan freq.: 24-30 Hz/47-120 Hz
• UHD: @ 24/25/30/50/60 Hz
• Mains voltage range: 100-240 +/-10% (50/60 Hz)
• Power consuption: 410W (normal mode), <0.5W (stand-by)
• Projector weight: 17 Kg. / 37.5 lbs
• Projector dimensions (WxHxD): 450 x 181 x 420 mm (17.7” x 7.1” x 16.5”) - lever feet included in height
