Dane techniczne

Panel

Diagonal Size85"

TypeNew Edge, 60Hz

Resolution3840*2160 (Landscape)

Brightness(Typ.)350 (without glass), 220 (with glass) nit

Contrast Ratio4000:1

Viewing Angle(H/V)178/178

Response Time(G-to-G)6ms(Typ.)

Operation HourN/A

Sound

Speaker TypeBuilt in Speaker (10W x 2CH)

Connectivity

Input

VideoHDMI 2(Rear 1, Front 1), DP 1, OPS I/F

USB2(Rear/Front), 2.0/3.0 External(Front)

Output

VideoHDMI 1 (Screen Share in Front)

Audio1(Stereo Mini Jack)

Touch OutTouch Out 2 (USB Upstream Type, Front 1, Rear 1)

External ControlTouch Input

Touch

TypeIR

# of Drawing4 drawing

Touch Pen TypePassive Pen with magnet

Object Recognition Range2mm/ 4mm / 8mm / 50mm (Brush Mode : Dynamic Object Recognition)

Power

TypeInternal (Main 1ea, OPS 1ea)

Power SupplyAC 100~240V 50/60Hz

Power Consumption

Max[W/h]418 (OPS 19V/3.7A)

Stand-by (W)0.5

Typical[W/h]151

Rating[W/h]380 (OPS 19V/3.7A)

BTU(Max)1,425.38 (OPS 19V/3.7A)

Mechanical Specification

Dimension (mm)

Set1942.8(W) x 1144.1(H) x 69.4(D)

Package2136(W) x 1311(H) x 260(D)

Weight (kg)

Set74.5

Package91.5

ColorCharcoal Black

VESA Mount (mm)600 x 400

Protection GlassYes

Stand TypeWall Mount

Media Player Option TypeOPS Slot support

RotationLandscape only

Power Cable Length3M

Bezel Width (mm)Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Waranty/QSG

Operation

Operating Temperature0  ℃  ~   40   ℃

Humidity10  %  ~   80   %   non-condensing

Feature

Key FeaturesFlip App

Special FeaturesH/W: Touch Overlay(IR), Front Connectivity(Tray), OPS I/F Support(w/OPS Box) Built in Speaker(10W x 2), WiFi/BT Module Embedded S/W: Flip S/W Platform: Muse-M (Tizen 5.0)

Internal Player

ProcessorCA72 Quad(1.7GHz) 2MB L2

On-Chip Cache MemoryL2 : 2MB

Clock Speed1.7GHz CPU Quad

Main Memory InterfaceLPDDR4 1.6GHz 64bit 2.5GB

GraphicsGPU : MaliG51 MP4@760MHz

Storage (FDM)8GB (2.65GB Occupied by O/S, 5.35GB Available)

MultimediaN/A

IO PortsUSB 2.0

Operating SystemTizen 5.0 : Samsung Proprietary OS(VDLinux)

Certification

SafetyN/A

EMCN/A

Security802.1x(WPA2 Enterprise): EAP-TLS, EAP-TTLS, EAP-PEAP

Accessory

IncludedPower Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Waranty/QSG

Optional

StandN/A

MountWMN8200SF

SpecialtyFlip UX

Media Player

Media Player

Media PlayerN/A
