Panel
Diagonal Size
85"

Type
New Edge, 60Hz
Resolution
3840*2160 (Landscape)

Brightness(Typ.)
350cd (without glass) nit

Viewing Angle(H/V)
178:178

Response Time(G-to-G)
6ms(Typ.)
Display Colors
16.7M
Operation Hour
N/A
Sound
Speaker Type
Built in Speaker (10W x 2CH)
Connectivity
Input
Video
HDMI 2(Rear 1, Front 1), DP 1, OPS I/F

USB
2(For SoC, Rear/Front), 2 (for external 2.0 x1/3.0x1(Front))
Output
Video
HDMI 1 (Screen Share in Front)
Audio
1(Stereo Mini Jack)
Touch Out
Touch Out 2 (USB Upstream Type, Front 1, Rear 1)
External Control
Touch Input / RS232C thru stereo jack, RJ45(For MDC)
Touch
Type
IR
# of Drawing
4 drawing (Internal) 20 touch (External)
Touch Pen Type
Passive Pen with magnet
Object Recognition Range
2mm/ 4mm / 8mm / 50mm (Brush Mode : Dynamic Object Recognition)
Haze
8%~12%
Thickness
3.2T
Hardness
Heat Semi-Strengthened Glass
Additional Film
AG, Hydrophobic Coated PET
Power
Type
Internal (Main 1ea, OPS 1ea)
Power Supply
AC 100~240V 50/60Hz
Power Consumption
Max[W/h]
418 (OPS 19V/3.7A)

Stand-by (W)
0.5
Typical[W/h]
151

Rating[W/h]
380 (OPS 19V/3.7A)
BTU(Max)
1,425.38 (OPS 19V/3.7A)
Mechanical Specification
Dimension (mm)
Set
1942.8x1144.1x69.4 mm
Package
2136x1311x260 mm
Weight (kg)
Set
74.5 kg
Package
91.5 kg
Color
Charcoal Black
VESA Mount (mm)
600 * 400
Protection Glass
Yes
Stand Type
Wall Mount
Media Player Option Type
OPS Slot support
Rotation
Landscape only
Power Cable Length
3M /2.4M(US)
Accessory
Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Waranty/QSG
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10 % ~ 80 % non-condensing
Feature
Key Features
Flip App

Orientation
Landscape

Remote Control
N/A
Special Features
H/W
Touch Overlay(IR), Front Connectivity, OPS I/F Support(w/OPS Box) / Built in Speaker(10W x 2), WiFi/BT Module Embedded

S/W
Flip S/W

Platform
Muse-M (Tizen 6.0)
Internal Player
Processor
CA72 Quad(1.7GHz) 2MB L2

On-Chip Cache Memory
L2 : 2MB

Clock Speed
1.7GHz CPU Quad

Main Memory Interface
LPDDR4 1.6GHz 64bit 3.0GB
Graphics
GPU : MaliG51 MP4@760MHz

Storage (FDM)
16GB

Multimedia
N/A

IO Ports
USB 2.0
Operating System
Tizen 6.0 : Samsung Proprietary OS(VDLinux)
Certification
Safety
N/A

EMC
N/A

Security
802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Accessory
Included
Power Cord, USB Upstream Cable(1ea), Pen(2ea, Black), OPS Box, Waranty/QSG
Optional
Stand
N/A

Mount
WMN8200SF

Specialty
Flip UX
Media Player
Media Player
Media Player
N/A
