DANE TECHNICZNE

Panel

Diagonal Size46"

TypeD-LED DID

Resolution1920*1080 (Full HD)

Pixel Pitch(mm)0.53025mm(H) * 0.53025mm(V)

Active Display Area(mm)1018.08mm * 572.67mm

Brightness(Typ.)500 nit

Contrast Ratio4000:1

Viewing Angle(H/V)178/178

Response Time(G-to-G)8ms

Display Colors8 bit - 16.7M

Color Gamut72%

Haze25% (Outer Haze 23%)

Display

Dynamic C/RMEGA DCR

H-Scanning Frequency30kHz ~ 81kHz

V-Scanning Frequency48Hz ~ 75Hz

Maximum Pixel Frequency148.5MHz

Sound

Speaker TypeN/A

Connectivity

Input

RGBAnalog D-SUB, DVI-D, Display Port 1.2

VideoHDMI 2.0 (2)

HDCPHDCP 2.2

AudioStereo mini Jack

USBOnly F/W upgrade

Output

RGBDP1.2(Loop-out)

VideoN/A

AudioStereo mini Jack

Power OutN/A

External ControlRS232C(in/out), RJ45

External SensorDetachable type(IR, Ambient)

TunerN/A

Power

TypeInternal

Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption

Max[W/h]143

Typical[W/h]79

BTU(Max)488

Sleep modeless than 0.5W

Off modeless than 0.5W

Mechanical Specification

Dimension (mm)

Set1020.0 x 574.6 x 96.3

Package1153 x 719 x 295

Weight (kg)

Set15.7kg

Package21.6kg

VESA Mount (mm)600 * 400 (mm)

Mounting HoleN/A

Protection GlassN/A

Stand TypeN/A

Media Player Option TypeN/A

Bezel Width (mm)1.15mm(U/L), 0.55mm(R/B)

Operation

Recommended Usage Hours24/7

Operating Temperature0  ℃  ~   40   ℃

Humidity10  %  ~   80   %

Feature

Key FeaturesExtreme Narrow Bezel

Special FeaturesACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 25%, Temperature Sensor, RS232C/RJ45 MDC,Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(80hrs Clock Keeping)

Internal Player

ProcessorN/A

On-Chip Cache MemoryN/A

Clock SpeedN/A

Main Memory InterfaceN/A

GraphicsN/A

Storage (FDM)N/A

MultimediaN/A

IO PortsN/A

Operating SystemN/A
