Strona głównaMONITORY MULTIMEDIALNESAMSUNGMonitor Do Ścian Wideo Samsung SMART Signage UH46F5 (LH46UHFCLBBEN)
Samsung

Monitor Do Ścian Wideo Samsung SMART Signage UH46F5 (LH46UHFCLBBEN)

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Monitor Do Ścian Wideo Samsung SMART Signage UH46F5 (LH46UHFCLBBEN)

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu

Panel

  • Diagonal Size46"
  • TypeD-LED DID
  • Resolution1920*1080 (Full HD)
  • Pixel Pitch(mm)0.53025 (H) x 0.53025(W)
  • Active Display Area(mm)1018.08(H) x 572.67(V)
  • Brightness(Typ.)700 nit
  • Contrast Ratio4000:1
  • Viewing Angle(H/V)178/178
  • Response Time(G-to-G)8ms
  • Display Colors8 bit - 16.7M
  • Color Gamut72%
  • Haze11%

Display

  • Dynamic C/RMEGA DCR
  • H-Scanning Frequency30kHz ~ 81kHz
  • V-Scanning Frequency48Hz ~ 75Hz
  • Maximum Pixel Frequency148.5MHz

Sound

  • Speaker TypeN/A

Connectivity

Input
  • RGBDVI-D, Display Port 1.2
  • VideoHDMI 2.0 (2)
  • HDCPHDCP 2.2
  • AudioStereo mini Jack
  • USBOnly F/W upgrade
Output
  • RGBDP1.2(Loop-out)
  • VideoN/A
  • AudioStereo mini Jack
  • Power OutN/A
  • External ControlRS232C(in/out), RJ45
  • External SensorDetachable type(IR)
  • TunerN/A

Power

  • TypeInternal
  • Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
  • Max[W/h]132
  • Typical[W/h]98
  • BTU(Max)450
  • Sleep modeless than 0.5W
  • Off modeless than 0.5W

Mechanical Specification

Dimension (mm)
  • Set1023.8 X 578.4 X 47.9
  • Package1171x734x277
Weight (kg)
  • Set13.5kg
  • Package19.5kg
  • VESA Mount (mm)400 * 400 (mm)
  • Mounting HoleN/A
  • Protection GlassN/A
  • Stand TypeN/A
  • Media Player Option TypeN/A
  • Bezel Width (mm)3.4mm(U/L), 2.0mm(R/B)

Operation

  • Recommended Usage Hours24/7
  • Operating Temperature 0.0  ℃  ~   40.0   ℃
  • Humidity 10.0  %  ~   80.0   %

Feature

  • Key FeaturesThinnest Depth, Super Narrow Bezel
  • Special Features ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 11%, Temperature Sensor, RS232C/RJ45 MDC,Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(80hrs Clock Keeping)
Internal Player
  • ProcessorN/A
  • On-Chip Cache MemoryN/A
  • Clock SpeedN/A
  • Main Memory InterfaceN/A
  • GraphicsN/A
  • Storage (FDM)N/A
  • MultimediaN/A
  • IO PortsN/A
  • Operating SystemN/A

Certification

  • SafetyUL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1
  • EMCFCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea) :KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB9254-2008, GB17625.1-2012
  • IP RatingIP5x

Accessory

  • IncludedQuick Setup Guide, Warranty Card, DP cable, stereo to DB9 cable, Power Cord, Remote Controller, Batteries
Optional
  • StandN/A
  • Mount WMN-46VD
  • SpecialtyN/A

Media Player

Media Player
  • Media PlayerSBB, Signage player box
