Specyfikacja techniczna

Panel Specifications

Diagonal Screen Size: 48.5"

Aspect Ratio: 16:9

Resolution: 1920 x 1080 (Full HD)

Panel Technology: IPS 10-Bit

Backlight: Direct-LED

Contrast Ratio: 14300:1

Brightness: 450 cd/m² / nit

Colour Support: 1.07Bln 10bit

Response Time: 12ms

Operation Hours: 24 Hours / 7 Days Non-Stop

Mounting Format: Landscape & Portrait

Includes Mount: No (Sold above)

Integrated Speakers: 2 x 10 Watt

Warranty: 3 Year UK De-Install/Re-Install Warranty

Anti-glare treatment: 10% Haze

Button & IR Lock-Out Function: Yes

OPS Expansion Slot: Yes (OPS Not Included)

Signage Features

Daisy Chain: DisplayPort, DVI, VGA (via DVI)

Video Daisy Chain: Up to 40 Screens

IR Daisy Chain: Yes

RS-232C Daisy Chain: Yes

Plug & Play: No

Software Bundled: SmartControl Software

Supported Cloud Software: CMND

Wi-Fi / Wireless: No

LAN / RJ45: Yes

Dimensions & Weight

Bezel Gap: 3.5mm

Bezel Width (top/bottom/left/right) (mm): 2.3 / 1.2 / 2.3 / 1.2 mm

VESA Mount Pattern: 400 x 400 mm

Dimensions (W x D x H): 1,213.4 x 684.2 x 107.65 mm

Weight: 29.2 Kg

Inputs & Outputs

VGA In x 1

VGA (via DVI) Out x 1

HDMI In x 2

DisplayPort 1.2 In x 1

DisplayPort Out x 1

DVI-D In x 1

DVI-I Out x 1

Component (RCA) In x 1

Composite (RCA) In x 1

Audio 3.5mm In x1

Audio Left/Right (RCA) In x1

Audio Left/Right (RCA) Out x1

External Speaker Out x1

RS-232C 2.5mm Jack In x1

RS-232C 2.5mm Jack Out x1

IR 3.5mm Jack In x1

IR 3.5mm Jack Out x1

RJ45 In x 1

OPS In x1
