Dane techniczne:

Screen size (diagonal) (inch)

54.6-inch

Screen size (diagonal) (mm)

1387 mm

Aspect Ratio

16:9

Panel Type

VA Panel / D-LED

Effective display area (W x H) (mm)

1209 x 680

Effective display area (W x H) (inch)

47.6" x 26.7"

Resolution

3840 x 2160

Brightness (typ.)

400 cd/m2

Contrast Ratio

4000 : 1

Response Time

8 ms (G to G)

Terminals | HDMI IN

HDMI Type A Connector x 2

Terminals | PC IN/AUDIO IN (L/R)

Mini D-Sub 15-pin (DDC2B) x 1

Terminals | USB

USB Type A Connector x 1, DC 5 V/0.5 A (USB 2.0 is supported)

Terminals | Serial

D-sub 9pin x 1, RS-232C Compatible

Terminals | LAN

RJ45 x 1

RJ45 10BASE-T/100BASE-TX

Built-in Speaker

20 W [10 W + 10 W]

Power Requirements

AC 110 - 127 V 50 Hz / 60 Hz

Power consumption

128 W

Power Off Condition

Approx. 0.5 W

Standby Condition

Approx. 0.5 W

Dimensions (W x H x D) (mm)

1240 x 718 x 80 mm

Dimensions (W x H x D) (inch)

48.9" x 28.3" x 3.2"

Bezel width (mm)

T/R/L11.9 mm B14.7 mm

Bezel width (inch)

T/R/L 0.47"  B 0.59"

Weight (kg)

Approx.15 kg

Weight (lbs.)

Approx. 33.1 lbs

Wall-hanging pitch (mm)

VESA Compliant (400 x 200 mm) (Installed by: M6 screws / Screw hole depth(17 mm))

Wall-hanging pitch (inch)

VESA Compliant 15.7" x 7.9"(Installed by: M6 screws / Screw hole depth 0.7"

Operating environment

Temperature : 32°F to 104°F (0℃ to 40℃)*1 : 32°F to 95°F (0℃ to 35℃)*2

Humidity : 20% to 80% (No condensation)

Operating Time

16 h/day

Viewing angle [(T/B)/(L/R)]

178° / 178° (CR≧20)

Terminals | AUDIO OUT

RCA Terminal (L / R) x 1

Variable (- ∞ - 0 dB) (1 kHz 0 dB Input,10 kΩ Load)

0.5 V [rms]

Terminals | IR Out

Pin Jack x 1
