Panasonic TL-55LV12AW wyświetlacz LED Video Wall
DISPLAY PANEL -> Screen Size(Diagonal) 55-inch class (1395.1 mm/54.92-inch)
DISPLAY PANEL -> Brightness (typ.) 800 cd/m²
DISPLAY PANEL -> Aspect ratio 16:9
DISPLAY PANEL -> Resolution 960 x 540(Max input resolution:3840 x 2160)
DISPLAY PANEL -> Contrast Ratio (typ.) 10,000:1
DISPLAY PANEL -> LED type / Pixel pitch 3-in-1 COB / 1.26 mm
INSTALLATION -> Orientation Landscape/Portrait
INSTALLATION -> Operating Time *2 24h / day
DISPLAY PANEL -> Panel life time (typ.) *1 Approx. 100,000 hours
ELECTRICAL -> Power Supply AC 110-240 V 50/60 Hz 1.77 A-0.94 A
ELECTRICAL -> Power Consumption 170 W(Shipping Condition) 800cd/m2
195 W(rating)
MECHANICAL -> Dimension(W x H x D) 1216 x 684 x 29 mm (47.88" x 26.93" x 1.13")
MECHANICAL -> Weight Applox. 18.3 kg / 40.4 lbs.
MECHANICAL -> Pitch for Wall-Hanging / Screw / Screw hole depth VESA compliant 400 x 400 mm (15.8" x 15.8"), M6 (Screw hole depth: 10 mm (0.39"))
CONNECTION TERMINAL -> AC Input x 1 IEC C14
CONNECTION TERMINAL -> HDMI™ IN HDMITM TYPE A Connector × 1, Compatible with HDCP 2.2
CONNECTION TERMINAL -> HDMI™ OUT HDMITM TYPE A Connector × 1 (for system expansion)
CONNECTION TERMINAL -> IR IN Stereo mini jack (φ 3.5 mm) x 1
CONNECTION TERMINAL -> USB TYPE C USB Type C connector x 1 (DC 5 V / 1 A, USB 2.0 is supported, for PC control)
Other -> External control LAN/Remote controller
Other -> Remote controller Yes
ELECTRICAL -> Apparent power 220 VA
CONNECTION TERMINAL -> LAN(For PC Control) RJ45 10BASE-T
CONNECTION TERMINAL -> LAN(For system expansion) RJ45 10BASE-T
INSTALLATION -> Tilting Angle 0 degrees
ENVIRONMENTAL -> Operating Environment(Temperature) 0 °C to 40 °C (32 °F to 104 °F)*3, 0 °C to 35 °C (32 °F to 95 °F)*4
Footnote Description
When the panel lifetime is at 50 % of the brightness under the condition of 25 degrees Celsius (+/- 2 degrees Celsius).
In case of running for a long time, the moving image is recommended to be displayed. If you display a still picture for an extended period, the image retention might remain on the screen. However,image retention can gradually disappear by displaying movie images.
for up to 4593 ft (1400 m) altitude
for between 4593 ft (1400 m) and 9186 ft (2800 m) altitude
