Display Technology Single 0.48” DMD S410, DC3 chip DLP® Technology by Texas Instruments

Resolution 1080p 1920 x 1080

Brightness 3400 ANSI lumens

Contrast Ratio 20,000:1

Lamp Life2 Dynamic/Eco/Bright/Education cycle 12000/10000/3500/15000 (hrs)

Throw Ratio 3 1.58 - 2.06

Zoom Type 1.3x (Optical), 0.8-2.0x (Digital)

I/O Connectors 2xHDMI (with MHL), VGA-in, composite, audio-in (3.5mm), audio-out (3.5mm), USB power, RS-232C

Speaker (Watts) 10W

Audio 10W

Keystone Correction ± 40° Vertical

Weight 6.75 lbs.

Dimensions (W x D x H) 12.44” x 4.27” x 9.2”

Aspect Ratio 16:9 native, 4:3, 16:10 and LBX compatible

Offset 116%±5%

Projection Screen Size 27” - 299”

Projection Distance 3.9’ - 33.46”

Projection Lens F=2.43 ~2.78, f=16.91 ~ 21.60mm manual

Uniformity 70%

Maximum Resolution WUXGA (1920x1200)

Computer Compatibility FHD, HD, WXGA, UXGA, SXGA, XGA, SVGA, VGA, Mac

Video Compatibility PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)

3D Compatibility Side-by-side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-under: 1080p24, 720p50 / 60

Horizontal Scan Rate 25 - 85Hz (120Hz for 3D)

Vertical Scan Rate 15 - 91kHz

Displayable Colors 1.07 billion

Noise Level (Eco mode) 27/32db

Power Supply AC input 100–240V, 50–60Hz, auto-switching

Power Consumption 300W Typical (Bright mode), 330W Max (Bright mode), 210W Typical (Eco+ mode), 230W Max (Eco+ mode)

Lamp Type 240W

Operating Conditions 41–104°F (5–40°C), 85% max humidity - Operating temp @ sea level up to 10000 feet = 23F (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)

Operating Temperature Operating temp @ sea level up to 10000 feet = 23F (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)

Security Security bar, Kensington lock, password protection

Remote Control Full size remote

Standard Accessories AC power cord, remote control, carrying case, batteries for remote, multilingual CD-ROM user’s manual, quick start card, and warranty card

Optional Accessories Universal ceiling mount, DLP®LinkTM 3D glasses, lamp, remote

Optional Wireless Yes

Warranty 3 Years

RoHS Compliant

Projection method Front, rear, ceiling mount, table top

Warranty 3-year Optoma Express Service, 1-year on lamp

1Lamp based projectors brightness and lifetime will vary depending on selected projector mode, environmental conditions and usage. As is common with all lamp based projectors, brightness will decrease over the lamp lifetime. LED projectors do not have a replaceable lamp and the brightness does not decay significantly over the product lifetime.

2Typical lamp life achieved through testing. Will vary according to operational use and environmental conditions

3 +/- 5% tolerance
