Specyfikacja

Display/image

Display technology

DLP

Resolution

1080p Full HD (1920x1080)

Brightness

3,600 lumens

Contrast ratio

20,000:1

Native aspect ratio

16:9

Aspect ratio - compatible

4:3

Keystone correction - vertical

40

Horizontal scan rate

15.38 ~ 91.15Khz

Vertical scan rate

50 ~ 85(120 for 3D)Hz

Uniformity

70%

Screen size

0.71m - 7.65m (28in - 301in)(Diagonal)

Lamp info

Light source

Lamp

Lamp watts

240

Lamp life (hours)

4000 (Bright), 12000 (Dynamic), 10000 (Eco), 15000 (Eco+)

Optical

Throw ratio

1.47:1 - 1.62:1

Projection distance (m)

1m - 9.8m

Zoom

1.1

Zoom type

Manual

Focal length (mm)

15.59 ~ 17.14

Native offset

116%

Connectivity

Connections

Inputs 1 x HDMI 1.4a 3D support, 1 x VGA (YPbPr/RGB), 1 x Composite video, 1 x Audio 3.5mm

Outputs 1 x Audio 3.5mm, 1 x USB-A power 1.5A

Control 1 x RS232

General

Noise level (typical)

27dB

PC compatibility

FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac

2D compatibility

NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)

3D compatibility

Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60

3D

Full 3D

Security

Security bar, Kensington Lock, Password protected interface

OSD / display languages

25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish, Vietnamese

Operating conditions

5°C ~ 40°C, Max. Humidity 85%, Max. Altitude 3000m

Remote control

Card style

Speaker count

1

Watts per speaker

10W

In the box

AC power cord, remote control, Battery, basic user manual

Power

Power supply

100 ~ 240V, 50 ~ 60Hz

Power consumption (standby)

0.5W

Power consumption (min)

205W

Power consumption (max)

295W

Weight and dimensions

Net weight

2.91kg

Dimensions (W x D x H) (mm)

316 x 244 x 108
