TECHNICAL SPECIFICATIONS

• Aspect Ratio: 16:9 (native), 4:3 and LBX compatible
• Audio: NuForce 40W Dolby Digital 2.0 soundbar with 2 full range aluminum drivers, 2 woofers and ported chambers. Sound effects: Movie, Music, Sport, Game, Night Bluetooth speaker mode support
• Brightness: 3,500 ANSI lumens
• Color Wheel: RGBYRGBY 8 segment color wheel
• Connections: 1x HDMI 2.0 (HDCP 2.2), 1x HDMI 2.0 (HDCP 2.2, HDMI-ARC), 1x HDMI 2.0 (HDCP 2.2, side), 1x USB 2.0 (4K media player), USB 2.0 power (side), USB, optical S/PDIF out, audio out, RJ45
• Contrast Ratio: Up to 2,500,000:1 with Dynamic Black
• Display Technology: Single 0.47” 4K UHD ECD DMD by Texas Instruments™
• Image Size: 85” – 120”
• Light Source Life: Up to 30,000/20,000 hours (Eco/Normal)
• Maximum Resolution: 4K (4096 x 2160) @ 30Hz
• Native Resolution: 4K UHD (3840 x 2160) @ 60Hz with XPR Technology
• Offset: 124% +6%/-2.5%
• Operating Temperature: 41–104°F (5–40°C), 85% max humidity
• Power Consumption: 410W max (Bright), 360W typical (Bright), 255W max (Eco), 225W typical (Eco)
• Power Supply: AC input 100–240V, 50–60Hz, auto-switching
• Projection Distance: 8” – 16.5” (from back of projector to projection surface)
• Projection Lens: F=2.04, f=525mm
• Projection Method: Tabletop
• Throw Ratio: 0.25:1 (distance/width) – 5% variance
• Zoom Type: 0.8 – 2.0x digital

COMPATIBILITY SPECIFICATIONS

• 3D Compatibility: Computer Compatibility
• Supports all HDMI 1.4a mandatory 3D formats and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e. 60 or 72 frames per eye). 3D glasses are needed and sold separately.: 4K UHD 2160p, 4K DC, WUXGA, HDTV 1080p, UXGA, SXGA, WXGA+, WXGA (1280 x 800), WXGA, HDTV (720p), XGA, SVGA, VGA, PC and Mac compatible

PHYSICAL SPECIFICATIONS

• Dimensions: 22.1” x 5.1” x 15”
• Security: Kensington® lock port, password (OSD)
• Weight: 24.25 lbs

OTHER

• Optional Accessories: Bluetooth smart home remote with airmouse (replacement), CinemaX Pro distance cards
• Standard Accessories: Bluetooth smart home remote with airmouse: BR-3074R, CinemaX Pro distance cards: BD-25120
• UPC: 796435 81 369 7
• Warranty Info: 5-year or 12,000 hour light source warranty (whichever comes first), 2-year parts and labor limited warranty on the projector.
