Display
Screen Size 65 inch
Active Display Area 1428.48 (H) mm × 803.52 (V) mm
Backlight Direct-lit LED backlight
Pixel Pitch 0.372 mm
Bezel Width 2.3 mm (top/left), 1.2 mm (bottom/right)
Resolution 3840 × 2160@60 Hz (downward compatible)
Brightness 500 cd/m²
Viewing Angle Horizontal 178°, vertical 178°
Color Depth 8 bit, 16.7 M
Physical Seam 3.5 mm
Contrast Ratio 1200: 1
Response Time 10 ms
Color Gamut 72% NTSC
Surface Treatment Haze 25%, 3H
Interface
Video & Audio Input HDMI × 1, DVI × 1, VGA × 1, DP× 1, USB × 1
Video & Audio Output HDMI × 1
Control Interface RS232 IN × 1, RS232 OUT × 1
Power
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption ≤ 260 W
Standby Consumption ≤ 0.5 W
Working Environment
Working Temperature 0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 10% RH to 80% RH (non-condensing)
Storage Temperature -20 °C to 60°C (-4 °F to 140 °F)
Storage Humidity 10% RH to 90% RH (non-condensing)
General
Casing Material SECC
VESA 800 (H) mm × 600 (V) mm
Product Dimension (W × H × D) 1432.58 (W) mm × 807.62 (H) mm × 85.1 (D) mm (56.4'' × 31.8'' × 3.35'')
Package Dimension (W × H × D)
Carton with a single display: 1630 (W) mm × 1013 (H) mm × 302 (D) mm (64.17'' ×
39.88'' × 11.89'')
Net Weight 29.2 ± 0.5 kg (64.37 ± 1.1 lb) for single display
Gross Weight Carton with a single display: 59.4 ± 0.5 kg (130.95 ± 1.1 lb)
Packing List
LCD display × 1, power cable × 1, network cable × 1, 2-meter HDMI cable × 1, screw ×
4, remote control × 1, IR receiver × 1, RS-232 converter × 1, quick start guide
(multilingual) × 1, quick start guide (English) × 1
 Physical Interface
Interface Description Interface Description
POWER Power indicator DVI IN
DVI-I input interface for
digital signals
LINE OUT
Audio output interface for
analog signals
RS 232 OUT
Serial loopback output
interface
HDMI OUT
HDMI output interface for
digital signals
RS 232 IN Serial input interface
HDMI IN
HDMI input interface for
digital signals
USB Reserved interface
DP IN
DP input interface for digital
signals
LAN Reserved interface
VGA IN
VGA input interface for
analog signals
IR IN IR input interface
100-240V~ Power input SWITCH Switch button
