Chassis
Occupied Slot
Output slot
Video Wall
Layers
16 layers per port (2K/4K)
Video Output
Video Output Interface Type
DVI-D
Video Output Interfaces
4
Video Output Resolution
1920 × 1200@60 Hz, 1600 × 1200@60 Hz, 1920 × 1080@60 Hz, 1680 × 1050@60 Hz,

1280 × 720@60 Hz, 1280 × 1024@60 Hz, 1024 × 768@60 Hz

Supports LED screen, custom resolution output, 60 Hz loading output, and 2.6 MP loading with width ranging from 144 to 4096 and height ranging from 144 to 2160.

Max. Video Output Resolution
1080p
Loading Capacity for Video Output to LED
Single port load 2600000,

Width 144 - 4096,

Height 144 - 2160;
