Chassis
Occupied Slot
Output slot
Video Output
Video Output Interface Type
HDMI 1.4
Video Output Interfaces
4
Video Output Resolution
1920 × 1200@60 Hz, 1600 × 1200@60 Hz, 1920 × 1080@60 Hz, 1680 × 1050@60 Hz,

1280 × 720@60 Hz, 1280 × 1024@60 Hz, 1024 × 768@60 Hz

Supports LED screen, custom resolution output, and load-based output. The product of the length and width must be less than 2.6 MP.

Max. Video Output Resolution
1080P
Loading Capacity for Video Output to LED
Single port load 2600000,

Width 288 - 3840,

Height 288 - 2160;

Audio Output
Audio Output Interface Type
HDMI composite audio
Audio Output Interfaces
4
