Chassis
Occupied Slot
Output slot
Video Output
Video Output Interface Type
HDMI 2.0
Video Output Interfaces
2
Max. Video Output Resolution
4K
Video Output Resolution
4096 × 2160@60 Hz, 4096 × 2160@30 Hz, 3840 × 2160@60 Hz, 3840 × 2160@30 Hz,

2560 × 1600@60 Hz, 2560 × 1440@60 Hz, 1920 × 1200@60 Hz, 1920 × 1080@60 Hz

Supports LED screen, custom resolution output, 60 Hz loading output, and 8.8 MP loading with width ranging from 288 to 7680 and height ranging from 288 to 4320.

Loading Capacity for Video Output to LED
Single port load 8800000,

Width 288 - 7680,

Height 288 - 4320;

Audio Output
Audio Output Interface Type
HDMI composite audio
Audio Output Interfaces
2
