Tech Spec
Panel
Screen Size 55"
Panel Technology OLED
Back Light Type OLED
Aspect Ratio 16 : 9
Native Resolution 1,920 × 1,080 (FHD)
Refresh Rate 120 Hz
Brightness 200 / 600 nit (APL 100% / 25%, without Glass)
Contrast Ratio 200,000 : 1
Dynamic CR No
Color gamut DCI 90%, BT709 110%
Viewing Angle (H x V) 178 × 178
Color Depth 10 bit (R), 1.07 Billion Colors
Response Time 0.1 ms (G to G), 8 ms (MPRT)
Surface Treatment (Haze) 3% (Set), Hard Coating (5 H)
Lifetime 30,000 Hrs (Typ.)
Operation Hours (Hours / Days) 18 / 7 (Moving Content Only)
Portrait / Landscape Yes / Yes
Transparency (Typ.) 43% (Set)
QWP (Quarter Wave Plate) No
Mechanical
Specification
Bezel Color Transparent
Bezel Width 7.9 / 7.9 / 7.9 / 121.8 mm (T/R/L/B)
Weight (Head) 11.6 kg (Head), 2.6 kg (Signage Box)
Packed Weight TBD
Monitor Dimensions (W × H × D) 1,225.5 × 810.1 × 14.6mm (Head),
Carton Dimensions (W × H × D) 1,345 × 920 × 246 mm
Protection Glass (Thickness) 3.0 mm
Protection Glass (Tempered / Chemical Strengthening) Chemical Strengthening
Protection Glass (Anti-Reflective) Yes (Film)
Protection Glass (Shatter-Proof) Yes
Feature
Key Feature Internal Memory (eMMC) 16 GB, Temperature Sensor, webOS 7.5, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, RS-232C Sync, Local Network Sync, Video Tag (4), Screen Rotation, External Input Rotation, Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, PM Mode, Wake on LAN, HDMI-CEC, SI Server Setting, Scan Inversion
Environment Conditions
Operation Temperature 0°C to 40°C
Operation Humidity 10% to 80%
Power
Power Supply AC 100-240 V~, 50/60 Hz
Power Type Built-in Power
Power Consumption
Typ./Max. 70 W (IEC 62087) / 230 W
DPM 0.5 W
Power off 0.5 W
BTU (British Thermal Unit) 239 BTU/Hr (Typ.), 785 BTU/Hr (Max.)
Standard (Certification)
Safety CB / NRTL
EMC FCC Class "A" / CE / KC
ErP Yes
Software Compatibility
SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare
Connectivity
Input HDMI (HDCP 2.2/1.4), DP (HDCP 1.3), RS-232C, RJ45 (LAN), IR (External IR Receiver), USB 2.0 Type A (2), Daisy Chain (HDMI, DP)
Output DP, Audio, RS-232C, RJ45 (LAN), IR (Sharing RS-232C), Daisy Chain (DP)
Language
English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Polski, Türkçe, Arabic
Accessory
Basic Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables (1,000 mm × 4 ea / 1,000 mm × 2 ea) for Connection Between Panel and Signage Box), DP Cable (2 m), LAN Cable (1.5 m), RS-232C Cable (4P-4P, 1.5 m), LC Cable(VLC, 3 m), Screw ((M3 × L5.5 Black (16 ea) / M3 × L3.5 Silver (20 ea) / M4 × L22 Black, (22 ea)), Cover Shield Assy, Cable Rubber, Rubber Damper (4 ea), Cable Holder (4 ea), Signage Box Wing Bracket (2 ea)
Optional No
Special Feature
Conformal Coating (Power Board) Yes
