PANEL
Screen Size 21.5"Panel Technology IPS
Back Light Type EdgeAspect Ratio 16:9
Native Resolution 1920x1080 (FHD)Refresh Rate 60Hz
Brightness 1300nit (Typ, w/ Glass)Contrast Ratio 1000:1 (Typ)
Dynamic CR 800,000:1Color gamut NTSC 72%
Viewing Angle(H x V) 178x178Color Depth 8bit, 16.7Million colors
Response Time 25ms (G to G)Surface Treatment(Haze) Anti glare, 3H(Haze 25%)
Life time 70,000 Hrs (Typ)Operation Hours (Hours/Day) 24/7
Portrait / Landscape Yes / YesQWP(Quarter Wave Plate) Yes (Apply on glass)
CONNECTIVITY(JACK INTERFACE)
Input HDMI (1, HDCP1.4), RS232C IN, RJ45(LAN), USB2.0 Type A (1)Output Touch USB, Externel Speaker Out (1, L/R, 10W+10W), RS232C OUT
MECHANICAL SPECIFICATION
Bezel Color BlackBezel Width 32.0mm(R/L), 27.0mm(T/B)
Weight(Head) 8.1 KgPacked Weight 9.7 Kg
Monitor Dimension(W x H x D) 554.7 x 325.8 x 60mmCarton Dimensions(W x H x D) (Box outer size) 644 x 406 x 207 mm
VESA™ Standard Mount Interface 100x100Protection Glass Depth 3mm, Tempered / Chemical strengthening (Thermal-strengthening), Shatter-Proof
KEY FEATURE
HW Internal Memory 16GB, Temperature Sensor, Auto Brightness sensor, Humidity Sensor, Acceleration(Gyro) Sensor, Power Indicator, FANSW webOS ver. (webOS4.1), Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (Local Network Sync), Video Tag (4, Max One HDMI input), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 50 °COperation Humidity 10 % to 80 %
POWER
Power Supply AC 100-240V~, 50/60HzPower Type Built-In Power
POWER CONSUMPTION
Typ. 85WMax. 115W
BTU (British Thermal Unit) 290(Typ), 393(Max)Smart Enegy Saving 40W
DPM 0.5W↓Power off 0.5W↓
CERTIFICATION
Safety CB / NRTLEMC FCC Class "A" / CE / KC / VCCI
ErP / Energy Star Yes / No
SOFTWARE COMPATIBILITY
SuperSign CMS YesSuperSign Control / Control+ Yes / Yes
Signage 365 Care Yes
LANGUAGE
OSD English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arab, Turkish
ACCESSORY
Basic Remote Controller(including battery 2ea),
Power Cord, Manual (EIG, IG), RS-232C Gender
SPECIAL FEATURE
Tilt(Facedown) Yes (Max -15º degree, Face Down) PPIP Rating IP66 (Front Only)
Direct Sunlight Yes
