PANEL
Screen Size 55"Panel Technology IPS
Back Light Type DirectAspect Ratio 16 : 9
Native Resolution 3840x2160 (UHD)Refresh Rate 60 Hz
Brightness 440nit(wo Glass, max), 390nit (wo Glass, typ)
400nit(w Glass, typ), 350nit (w Glass, typ)Contrast Ratio 1200:1
Dynamic CR 50,000:1Color gamut NTSC 72%
Viewing Angle(H x V) 178°(H/V)Color Depth 10bit(8bit + FRC)
Response Time 8 msSurface Treatment(Haze) Haze 25%
Life time 50,000hrs (L30)Operation Hours (Hours/Day) 16/7
Portrait / Landscape No / Yes
CONNECTIVITY(JACK INTERFACE)
Input HDMI (3, HDCP2.2), RGB (1, VGA), Audio In, RS232C IN, RJ45(LAN), USB3.0 Type A (4), USB2.0 Type A(1), USB Type-C(1, USB-PD, DP-Alt,)Output DP Out (HDMI Out), Audio Out (1, Optical 1(SPDIF)), Touch USB (2), RJ45(LAN)
MECHANICAL SPECIFICATION
Bezel Color BlackBezel Width T/R/L/B : 18/18/18/45mm
Weight (Head) 26.1KgPacked Weight 34.5Kg
Monitor Dimension(W x H x D) 1271×774×87mmCarton Dimensions(W x H x D) (Box outer size) 1401×859x220mm
Handle YesVESA™ Standard Mount Interface 400×200mm
KEY FEATURE
HW Internal Memory (32GB), Built-in Wi-Fi (Slot type), Auto Brightness sensor, Power IndicatorSW webOS ver. (Android 11.0), Background Image (Booting Logo Image), Multi-screen (PIP (1 external source), PBP(1 external source)), Screen Share (LG CreateBoard Share), Power (Smart Energy Saving (Energy Saving))
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C ~ 40 °COperation Humidity 10 ~ 90 % RH
POWER
Power Supply 100-240V~ 50/60Hz 3.5APower Type Built-In Power
POWER CONSUMPTION
Typ. 170Max. 395
BTU (British Thermal Unit) 580 BTU/Hr(Typ.), 1348 BTU/Hr(Max)DPM ≤0.5W
Power off ≤0.5W
SOUND
Speaker Yes (15W x 2)
CERTIFICATION
Safety CB / NRTLEMC FCC Class "A" / CE / KC
ErP / Energy Star Yes / Yes
OPS COMPATIBILITY
OPS Type Compatible Yes (Slot)OPS Power Built In Yes
SOFTWARE COMPATIBILITY
LG ConnectedCare YesLG ConnectedCare DMS Yes (DMS)
LANGUAGE
OSD English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Spanish, Swedish, Hungarian, Thai
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional Wall Mount(WM-L000S), Floor Stand(ST-000F)
SPECIAL FEATURE
Touch - Available object size for touch Ø2 mm ↑ .Touch - Reponse Time ≤5ms
Touch - Accuracy ±1mmTouch - Interface USB2.0
Touch - Protection Glass Thickness 3T (Anti-Glare)Touch - Protection Glass Transmission 88%
Touch - Operating System Support Windows 7/8/10/Linux/Mac/Android
(Linux/Mac Support one point touch)Touch - Multi touch point Max 40 points
ANDROID SYSTEM
SoC Quad core A55GPU Mali G52MP2
Internal Memory - Storage 32GBInternal Memory - RAM 4GB
Wi-Fi 802.11a/b/g/n/ac/ax (WiFi 6)LAN Gigabit LAN
Bluetooth Bluetooth 5.0
