Active Display Area (mm) 1018.08 x 572.67

Resolution 1920 x 1080

Aspect Ratio 16:9

Display Colors 1.07B

Brightness (cd/m²; typ.) 500

Contrast Ratio 4000:1

Response Time (ms; GTG) 6.5

Viewing Angle 178°/178°

Lifetime (hours) 50,000

Backlight type LED

Touch Screen

Resolution 11456 x 6400

Response Time (ms) Touch : 10, Drawing : 15.2

Glass Transmission: 93%, Thickness: 5mm with anti-vandal

Available object size

for Touch (mm)

Touch : Ø 6

Stylus : Ø 7

Others USB 2.0 | Touch Intensity : Over 60,000,000 | Detection Method : Infrared Rays

Resolution

Monitor 1920 x 1080

DTV 1080p

Connectivity

Input 1x DVI | 1x HDMI | 1x VGA(D-Sub) | 1x PC Audio | 1x RS232C | 1x IR sensor

Output 1x DVI | 1x RS232C | 1x Audio Line out | 1x IR sensor

Power

Input Voltage 100 – 240V AC

Power consumption 110 W

Features

PIR Sensor (Motion detection) option

Built in speaker option

Auto Power Control yes

Auto Brightness Sensor no

Operation Temperature (ºC) 0 - 40

Humidity (%) 20 - 80

OSD Language 10 Lang

Dimension Set (W x H x D), mm TBD

Bezel Size (U/D/L/R), mm TBD

Wall Mounting (WxH), mm 400 x 400 / 600 X 400

Weight Set (kg) TBD
