Dane techniczne:

Display Details

Display area 2158.8*1214.4 mm

BacklightType LED

Brightness 500cd/m2

Display ratio 16:9

View Angle 89°

Contrast Ratio 1400:1

View Angle 178°

Picture model 16:9/4:3/dot to dot/full screen

Resolution UP to 3480*2160

Orientation Landscape

Displayable Colors RGB

Minimum life length panel 50.000 hours Standard Energy Star

Monitor Details

Video Mode PAL, NTSC, SECAM

Sound Mode D/K,B/G,I, M

Resolution 1280*720/1280*960/1280 *1024/1024*768/1360*768/1440* 900/1600*1200/1920*1080/ 3480*2160

Response time <25ms

Input port USB input 2 x USB-A (horizontal)

PC-RGB input 2 x D-SUB 15Pin (blue)

PC Audio Input 2 x HDMI

RS232 1 x RS232

output port PC-RGB output 1 x D-SUB 15Pin (black)

Touch Monitor Details

Technology infrared

Glass Tempered glass/Anti-Glare glass Protective glass with 7 MOHS strength

Response Object Finger, Display Pen, Any transparent object

Points input 10

Accuracy Φ<3mm

Positioning resolution 4096*4096/16384*16384/32768*32768

Continuous speed <8ms

Cursor speed >120dot/s

PC port USB

OS(system) WINDOWS all/LINUX/MAC /Android

PC response System auto response

Electrical Details

Voltage range AC(90~240)V-50/60HZ

Power consumption standby:<1W / Rated power:<510W

Work temperature 32~1040C

Work Humidity 0~90%

Storage temperature -4~140C

Storage Humidity 0~90%

Optional Parts

OPS i3 CPU, 4GB RAM,500GB HDD

i5 CPU, 4 GB RAM, 500 GB HDD

i7 CPU, 4 GB RAM, 500 GB HDD

Dimensions and Weight

Product dimension 2227*1292*120 mm /±2mm Package

Size 2378*1455*307 mm/±5mm

Weight Net approx.158 kg /±2 kg

Weight Gross approx.190kg
