Dane techniczne:

Display

Displayarea 1538.88*865.62 mm

BacklightType LED

Brightness 350cd/m2

Display ratio 16:9

ViewingAngle 178°(deg)

Contrast ratio 4000:1

Picture model 16:9/4:3/dot to dot/full screen

Resolution Up to1920*1080

Orientation Landscape

Displayable Colors RGB

Minimum life length panel 50.000 hours

Monitor

Video Mode PAL, SECAM (/NTSC)

Sound Mode DK,BG,I,

Resolution 1280*960/1280*1024/1360*768/1440* 900/1600*1200/1920*1080@60Hz

Responsetime <17ms

Input Terminals

CVBS/Audio Input 1 x 3RCA (yellow, white, red)

YPbPr 1 x MINI 3.5 mm (three-in-one terminal

USB input 2 x USB-A (horizontal)

PC-RGB Input 2 x D-SUB 15 Pin (blue)

PC Audio Input 2 x 3.5 mm Stereo Audio-In jack (green)

HDMI input 3 x HDMI-A (horizontal), one inside

RS232 1 x RS232

Output Terminals

PC-RGB Output 1 x D-SUB 15 Pin (black)

Touch Monitor

Glass Temperedglass/Anti-Glare glass Protective glass with 7 MOHS strength

Technology infrared

Response object finger, pen, stylus pen, other object

Points input 10 Points

Accuracy Φ<3mm

Positioning resolution 4096*4096/16384*16384/32768*32768

Continuous speed <8ms

Cursor speed >180dot/s

PC port : USB

OS(system) WINDOWS all/LINUX/MAC /Android

PCresponse plug and play

Electrical

Voltagerange AC (100~240) V-50/60HZ

Powerconsumption standby <1W

Rated power <420W

Work temperature 0~400C

WorkHumidity 0~90%

Storagetemperature -10~500C

StorageHumidity 0~90%

Optional Parts

Glass OPS Mobile stand TransparentTempered glass, I3/I5,4G,500G

Dimension and Weight

Product dimension 1656*964*72 mm /±2 mm

Package Size 1785*1095*205 mm/±5 mm

Weight Net 75 ±2kg

WeightGross 95±2KG
