Dane techniczne:

Display

Display area 1428.5x803.5 mm

Backlight Type LED

Brightness 330cd/m2

Display ratio 16:9

Viewing Angle 178°(deg)

Contrast ratio 5000:1

Picture model 16:9/4:3/dot to dot/full screen

Resolution Up to1920*1080

Orientation Landscape

Displayable Colors RGB

Minimum life length panel 50.000 hours

Monitor

Video Mode PAL, SECAM (/NTSC)

Sound Mode DK,BG,I,

Resolution 1280*960/1280*1024/1360*768/1440* 900/1600*1200/1920*1080@60Hz

Response time <17ms

Input Terminals

Input Port 2*HDMI、2*VGA、1*YPBPR、1*AV、 2*USB

2.0、1*RS232

Output Terminals

Output port 1 x VGA

Touch Monitor

Glass Tempered glass/Anti-Glare glass Protective glass with 7 MOHS strength

Technology Infrared

Points input 10 Points

Accuracy Φ<3mm

Positioning resolution 4096*4096/16384*16384/32768*32768

Continuous speed <8ms

Cursor speed >180dot/s

PC port : USB

OS(system) WINDOWS all/LINUX/MAC /Android

PC response Plug and play

Electrical

Voltage range AC (100~240) V-50/60HZ

Power consumption standby standby:<1W

Rated power:<420W

Work temperature 0~40ºC

Work Humidity 0~90%

Storage temperature -10~50ºC

Storage Humidity 0~90%

Optional Parts

Glass OPS Mobile stand Transparent Tempered glass, I3/I5,4G,500G

Dimension and Weight

Product dimension 1547*936*93mm /±2mm

Package Size 1760*1190*500mm/±5mm

Weight Net approx.67±2kg

Weight Gross approx. 83±2KG
