Display
Screen Size 65 inch
Backlight DLED
Pixel Pitch 0.124 (H) × 0.372 (V) mm
Resolution 3840 × 2160 @60 Hz
Brightness 400 cd/m² (Typ.)
Color Depth 8 bit + FRC
Display Color 1.07G
Response Time 5ms
Panel Type VA
Contrast Ratio
5000:1 (Static)
30,000:1 (Dynamic)
Color Gamut 72% NTSC (CIE1931) (Typ.)
Refresh Rate 60 Hz
Viewing Angle 178°(H)/178°(V)
Aspect Ratio 16:9
Surface Haze 25% Haze
Display Area 1428.48 mm × 803.52 mm
Working Duration 7 × 16 H
Surface Hardness
9H (Pencil)
7 (Mohs)
Surface Glass 3.2 mm Anti-Glare Glass
Transmittance ≥ 88%
Lifespan 50,000 hours
Touch
Type Infrared Touch Screen
Touch Point 40-point multi-touch
Touch Response Time < 5 ms
Minimum Touch Object ≥ 2 mm (≥ 90% touching area)
Touch Precision ± 1 mm (≥ 90% touching area)
Touch Resolution 32767 × 32767
Built-in System
Operation System Android 13.0
Memory 8 GB
Built-in Storage 128 GB
CPU Cortex-A55 × 4 (1.92 GHz)
HDCP Version Support 1.4/2.2/2.3
GPU Mali-G52 MP2 (2EE)
Camera
Pixel Pixel 48 MP for Photos & 8 MP for Video
Camera Function Supports intelligent switching between Android system, OPS, and PC.
Field Angle 93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical)
Distortion ≤ 2.5%
Camera Resolution Ratio Up to 4K
Microphone
Specification Omni-directional 8-array layout
Mic Function Echo reduction and smart noise-cancellation
Voice Distance 12 m
Sampling Rate 32 K
Mic Depth 16 bit
Internal Function
Loudspeaker Built-in 2 × 20 W
Speaker Frequency 200-20Khz
Bluetooth Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.2
NFC Support card reader
Light Sensor Yes
Interface
Video & Audio Input HDMI In (HDMI 2.0) × 2, Audio In × 1
Video & Audio Output Audio Out × 1
Control Interface TOUCH-USB 2.0 × 1, RS232 × 1
Network Interface
LAN (100 Mbps) × 2
Wi-Fi AP & Station, 2.4G/5G
Wi-Fi AP: IEEE 802.11 a/b/g/n/ac 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication
protocols WEP, WPA, WPA2, PSK and 802.1X EAP
Wi-Fi Station: IEEE 802.11 a/b/g/n/ac/ax 1 × 1 MIMO (2.4 GHz and 5 GHz)
authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP
Data Transmission Interface USB 3.0 × 3, USB 2.0 × 2, Type-C × 1 (Type-C supports USB 2.0)
Power
Power Supply 100 to 240 VAC, 50/60 Hz
Standby Consumption ≤ 0.5 W
Max. Consumption 184 W
Average Consumption 153 W
General
VESA 600 mm × 400 mm (4 × M8-25 mm)
Net Weight 33.7 kg
Gross Weight 46.1 kg
Accessary
Wall mount bracket, hook, user manual, stylus × 2, packing list, 1.5 m power cable
(European standard), remote controller
Package Dimensions (W × H × D) 1662 mm × 1062 mm × 223 mm
Product Dimensions (With Wall
Attachment)
1491.88 mm × 914.6 mm × 113.84 mm
Product Dimensions (Without
Wall Attachment)
1491.88 mm × 914.6 mm × 82.3 mm
Working Environment
Working Temperature 0 °C to 40 °C (32 °F to 104°F)
Working Humidity 10%~90% RH
 Physical Interface
Interface Description Interface Description
1.Line OUT Audio output interface E.Type-C Type-C interface
2.Line IN Audio input interface F. Light sensor
3.RS 232 Serial port interface G. Remote-control unit
4.TOUCH-USB Peripheral touch interface H. NFC area
5.LAN 2 LAN 2 interface J. Power Key
6.LAN 1 LAN 1 interface K. Volume -
7.HDMI IN 1 HDMI 1 input interface L. Volume +
8.ANDROID USB Android USB interface M. Android host menu
9.MULTI-USB
Multi-functional USB
interface
N. Return
A.HDMI HDMI input interface P. Control menu
B.USB
Multi-functional USB
interface
Q. PC shutdown
C.USB
Multi-functional USB
interface
D.USB
Multi-functional USB
interface
