DS-D41Q30CA-1PH,indoor,3.067mm,320*160mm,3840hz

Product Model DS-D41Q30CA-1PH
Module
Pixel Configuration SMD Triad LED
Pixel Pitch 3.076 mm
Lamp Bead Dimension 1515
Dimension (W × H × D) 320 mm × 160 mm × 16.6 mm (12.60'' × 6.30'' × 0.65'')
Resolution 104 × 52
Pixel Density 105625
Signal Source Interface HUB75E
Display
White Balance Brightness 550 cd/m2
Color Temperature 3000 K to 10000 K adjustable
Viewing Angle 160°(H)/160°(V)
Brightness Uniformity ≥ 97%
Color Uniformity ≤ ± 0.003Cx, Cy
Contrast Ratio 3000:1
Refresh Rate 1920 Hz
Processing Performance
Scanning Amount 32
Grey Level Up to 16 bit
Power
Max. Consumption ≤ 420 W/m2
Average Consumption < 180 W/m2
Input Voltage DC: 4.5 V to 5 V
Working Environment
Working Temperature -10 °C to 40 °C (14 °F to 104 °F)
Working Humidity 10% RH to 80% RH (without condensation)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 10% RH to 85% RH (without condensation)
General
Package Dimension (W × H × D)
673 (W) mm × 453 (H) mm × 390 (D) mm (26.496" × 17.834" × 15.354")
(40 cabinets in 1 box)
Packing List
Several LED lamp beads and IC components
Several signal cables and power cables
Gross Weight 20 kg (4.41 lb)
Net Weight 16 kg (3.53 lb)
