Product Type
Product Form Highly-integrated
Product Characteristics Wired USB camera, wireless mirroring
Communication Protocol
Video Codec Protocol MJPEG, H264
Audio Codec Protocol PCM 16 bit depth 48 kHz, AAC-LC 16 bit depth 48 kHz
Other Communication Protocols UAC, UVC
WI-FI Standard Supports 2.4 G and 5 G dual-band connection
Bluetooth Supports 5.0 (only for the remote control)
Video Characteristic
Video Input Resolution
Capability
1 × HDMI IN, Max. 4K@30,
1 × Wireless Screen Mirroring, Max. 4K@30,
1 × Wireless Camera, Max. 1080P@30
Video Output Resolution
Capability
2 × HDMI OUT, Max. 4K@60,
1 × USB-C (UVC MJPEG), Max. 1080P@30
Audio Characteristic
Audio Algorithm
Audio Array Algorithm, Self-Adaption Audio Algorithm, Acoustic Echo Cancellation
(AEC), Automatic Noise Suppression (ANS), Automatic Gain Control (AGC)
AGC, Automatic Gain Control Supported
ANS, Automatic Noise
Suppression
Supported
AEC, Acoustic Echo Cancel Supported
Intelligent Noise Reduction Supported
Camera
Camera Type Built-In
Privacy Mask Electronic Privacy Cover
Sensor 1/2.8 inch, CMOS, Effective Pixel 8 Million
Max Resolution 4K@30 (3840 × 2160)
Aperture f/2.5
Focus Distance 2.02 mm
Backlight Compensation Supported
Horizontal Field Angle 109.9°
Vertical Field Angle 74.6°
Field Angle 118.8°
Digital Magnification 3x e-PTZ Electronic Head
Automatic Gain Supported
Automatic Exposure Supported
Preset Point Supported, 5 Presets; Supports Active Call, Update, Clear
DNR 2D & 3D
White Balance Supported, Automatic
Other
Supports to adjust image parameters, brightness, contrast, saturation, sharpness, gain
Supports a variety of view modes: Manual Mode, Smart View, Smart Tracking, Smart
Gallery
Microphone
Microphone type Built-In
Polar Pattern Omni-Directional
Pickup Range 6 m
Array Amount 8
Frequency Response Range 100-20 kHz
Sensitivity -38 db
Signal-to-noise Ratio 65 db
Sampling Rate 48 kHz
Loudspeaker
Rated Power 10 W
Sensitivity 78 dB ± 3 dB
Size 78 mm × 183.4 mm × 50 mm
Electrical Impedance 8 ± 1.2 Ω
F0, Lowest Frequency Response
Point
240 Hz
AI
Speaker Follow Supported
Intelligent Framing Supported
Smart Window Supported
Electronic Nameplate Supported
USB
Supported Operating System Supports Windows 7/10/11, and Mac OS
Video System
MJPEG (1080P@30 (1920x1080), 720P@30 (1280x720), 540P@30 (960x540),
360P@30 (640x360), 270P@30 (480x270)）
USB Audio PCM 16 bit depth 48 kHz
USB Video Communication
Protocol
UAC, UVC
Maintenance Function
Maintenance Mode Supported. Managed by remote control.
Maintenance Function
Supports device configuration, and upgrade via multiple methods ( USB flash drive /
cloud service online detection)
System
Operating System HIK WonderOS (Android 12)
Memory 8 GB + 16 GB
Interface
Video Input
1 × Built-in camera,
1 × HDMI IN
Video Output 2 × HDMI OUT
Audio Input 1 × 3.5 mm LINE IN
Audio Output 1 × 3.5 mm LINE OUT
Network Interface 1 × 10/100/1000 Mbps Self-Adaption Network
USB
1 × USB3.0 Type-C,
2 × USB2.0 Type-A
Power Interface DCJack, Φ2.0m
Bluetooth
1 × 2.4G Remote Control Bluetooth,
1 × 2.4G Audio Bluetooth
Wi-Fi 1 × 2.4 G & 5 G
Other Interface 1 × MIC (POE power supply, reserved interface)
General
Installation Screws + Buckles
Weigh(Product) 2.49 kg
Weight(With Packing) ≈ 5.360 kg
Dimension (Product) 616 × 145 × 104.23 mm
Dimension(With Packaging) 727 × 227 × 213 mm
Power Waste 24 W
Input Voltage DC 12V
Input Current 2A
Operating Temperature 0 to 40 °C
Operating Humidity 10%RH to 80%RH
Tripod Connecting Hole 1 × 1/4-20"Screw Hole
Heat Dissipation No heat dissipation holes. Internal aluminum block for heat dissipation.
Packing List
1 × Remote Control, 2 × Battery, 1 × AC Powerline, 1 × Power Adapter ( with
European/German plug adapter), 1 × Wall-Mounted Bracket, 1 × NFC Sticker, 1 ×
Expansion Screw, 1 × Quick Start Guide, 1 × Regulation Compliance and Safety
Information, 1 × Thank You Card, 1 × 5 m USB 3.0 Cable (USB-C to USB-A)
Certification Standard
Certification Certificate CB/CE, Certification of Transport
