Camera
Image Sensor 1/2.7" 2 MP CMOS
Max. Resolution 1920 (H)×1080 (V)
Min. Illumination 0.1 Lux @ (F2.2, AGC ON)
Shutter Time PAL: 1/25 s to 1/50,000 s,NTSC: 1/30 s to 1/50,000 s
Angle Adjustment Tilt: -10° to 10°
Zoom 2 ×
Lens
Lens Type 2.8 mm fixed focal lens
Focal Length ＆ FOV horizontal FOV 110°, vertical FOV 75°, diagonal FOV 120°
Depth of Field 0.3 m to ∞
Microphone
Type MEMS
Direction 360° Omni-directional
Pickup Distance In a radius of up to 5 m
Amount 4
Frequency Response 100 Hz to 8 kHz
Sensitivity -38 dBV/Pa
SNR 66 dB(A)
3A Algorithm AEC, ANS, AGC
Sampling Rate 16 kHz
Speaker
Rated Power 5 W
Maximum Output Loudness 87 dBSPL@1 m, 1 kHz
Speaker Range In the radius up to 8 m
Effective Bandwidth (-10 dB) 170 Hz to 20 kHz
Total Harmonic Distortion (THD) ＜3%@1 kHz
Functions
Image Function
Auto/Manual/Fixed White Balance, Backlight Compensation, Left/Right Flip / Up/Down
Flip/Center Mirror
Power Indicator
Solid red: low power (≤15%)
Solid orange: medium power (15%＜x≤30%)
Solid white: enough power (30%＜x≤100%)
Audio Function
Supports smart noise reduction, echo suppression, anti-reverberation, squeal
suppression to enhance speech quality and offer audio in high quality
LED Indicator
Solid Red: Mute
Solid White: Working Normally
No Light: Standby
Communication
Communication Method USB cable
Wired Communication Distance 2 m
Battery
Capacity 7.2 V/2450 mAh
Charging Temperature 0 ℃ to 45 ℃ (32 °F to 113 °F)
Discharging Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Temperature 0 °C to 35 °C (32 °F to 95 °F) for one year
Frame Rate
MJPG:
1920 × 1080@30 fps/25 fps
1280 × 960@30 fps/25 fps
1280 × 720@30 fps/25 fps
640 × 480@30 fps/25 fps
640 × 360@30 fps/25 fps
YUV2:
1920 × 1080@5 fps
1280 × 960@5 fps
1280 × 720@10 fps
640 × 480@30 fps/25 fps
640 × 360@30 fps/25 fps
H264:
1920 × 1080@30 fps/25 fps
1280 × 960@30 fps/25 fps
1280 × 720@30 fps/25 fps
640 × 480@30 fps/25 fps
640 × 360@30 fps/25 fps
Wide Dynamic Range (WDR) ≥120 dB
Interface
Cable Cable in package: Type C to Type A interface
Device Interface USB Type C interface
Compatibility
System Requirement
Recommended systems
Windows 7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
General
Power 5 VDC ± 5% (USB cable), max. 4.5 W
Material
Main body: Plastic with cloth
Base: Metal
Operating Condition -10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
Dimension Ø 91.7 mm × 271.3 mm (Ø 3.61" × 10.68")
Package Dimension 337 mm × 150 mm × 156 mm (13.27" × 5.91" × 6.14")
Weight Approx. 930 g (2.05 lb.)
With Package Weight Approx. 1465 g (3.23 lb.)
Color Silver gray
Packing List
Camera × 1
Privacy Shutter × 1
Remote Control (with battery) × 1
USB 3.0 cable (2 m) × 1
User Manual Card × 1
