Camera
Image Sensor 2 MP CMOS
Signal System PAL/NTSC
Max. Resolution 1920 (H) × 1080 (V)
Min. Illumination 0.1 Lux @ (F1.2, AGC ON)
Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night 24/7 Color Imaging
Angle Adjustment pan: 360°; tilt: -15° to 15°; ratation: 0°
Lens
Lens Type 3.6 mm fixed focal lens
Focal Length & FOV horizontal FOV: 86°, vertical FOV: 55°, diagonal FOV: 95°
Lens Mount M8
Object Distance Range 0.5 m to ∞
Frame Rate
MJPG:
1920 × 1080 @ 30/25 fps
1280 × 960 @ 30/25 fps
1280 × 720 @ 30/25 fps
640 × 480 @ 30/25 fps
640 × 360 @ 30/25 fps
YUV:
1920 × 1080 @ 5 fps
1280 × 960 @ 5 fps
1280 × 720 @ 5 fps
640 × 480 @ 30 fps
640 × 360 @ 30 fps
White Balance Auto
Audio
Audio Sampling Rate 16 kHz
Interface
Video Output USB 2.0
Audio Built-in mic
Indicator
White: Normally Working
Light Off: Standby
General
Operating Condition -10°C to 45°C, Humidity: 90% or less (non-condensing)
Material Plastic
Dimension 80.16 mm × 48.6 mm × 42.18 mm (3.16" × 1.91" × 1.66")
Weight Approx. 89 g (0.2 lb.)
Packing List
Camera × 1
Quick Start Guide × 1
Power DC 5V ± 5% (USB), Max. 1.2 W
Cable Length 1.5 m
System Requirement
Recommended systems
Windows 7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
