Product Model DS-D6055UN-DP
Display
Screen Size 55 inch
Resolution 3840 × 2160
Active Display Area 1219.70 (H) mm × 691.89 (V) mm
Pixel Pitch 0.315 (H) mm × 0.315 (V) mm
Backlight E-LED
Viewing Angle 178°(H)/178°(V)
Brightness 500 cd/m²
Contrast Ratio 5000:1
Color Depth 10 bit (8 bit + FRC)
Response Time 8 ms
Color Gamut 85% NTSC
Reliability 7 × 24h
Refresh Rate 60 Hz
Haze 25%
Built-in System
Operation System Android 13
Processor Cortex-A55, 4-core, main frequency 1.92 GHz
Memory 4 GB
Built-in Storage 32 GB EMMC
Interface
Video & Audio Input HDMI × 3, DP × 1
Video & Audio Output LINE OUT × 1, speaker (6Ω 10 W) × 2
Network Interface RJ45 × 1, Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax) × 1, RS232 in × 1, RS232 out × 1
Data Transmission Interface USB 2.0 × 1, USB 3.0 × 1, BT 5.0 × 1
Power
Input Voltage 100 to 240 VAC, 50/60 Hz
Standby Consumption ≤ 0.5 W
Power Consumption 75W (typ), 140W (max)
Working Environment
Working Temperature 0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 10% to 80% RH (Condensation)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 10% to 90% RH (Condensation)
General
Material Type DAT, VOB, TS, AVI, MKV, MOV, 3GP, FLV, ASF, MP3, WMA, OGG, JPG, BMP, PNG
Mounting Type Wall mounting (horizontally or vertically)
Product Dimensions (W × H × D)
1239.7mm × 712.5mm × 38.6 mm (without wall-mounted backboard)
1239.7mm × 712.5mm × 68.4 mm (with wall-mounted backboard)
Package Dimensions (W × H × D) 1390 mm × 850 mm × 136 mm
Net Weight 17.6 kg
Gross Weight 24.0 kg
Packing List
Digital Signage × 1, wall-mounted backboard (including package of mounting bolts) × 1,
power cord for Europe × 1, RS232 cable × 1, remote control × 1, user manual × 1, quick
start guide × 1, Regulatory Compliance and Safety Information × 1, logo stickers × 1,
energy efficiency label × 1
 Physical Interface
Interface Description Interface Description
LAN
100M/1000M Ethernet
interface
LINE OUT LINE output interface
RS232 OUT RS232 control out HDMI 1
HDMI digital signal input
interface
RS232 IN RS232 control in HDMI 2
HDMI digital signal input
interface
USB3.0 USB 3.0 interface HDMI 3
HDMI digital signal input
interface
USB2.0 USB 2.0 interface DP
DP digital signal input
interface
