SYSTEM
Effective Freq. Range
50-260Hz (-10dB)
Power handling
60 W RMS / 240 W Peak
Sensitivity
86 dB (1W/1m)
Maximum SPL
106 dB continuous / 112 dB peak
Power options (Hi Z Multi-tap)
100V: 60W / 30W / 15W / 7,5W / 8Ω
70V: 30W / 15W / 7,5W / 3,75W / 8Ω
Recommended amplifier power
120 W RMS
TRANSDUCERS
Ways
1 way subwoofer
Driver
6,5" woofer
Nominal impedance
8Ω
FILTERS
Low-Pass filter selector
OFF / 150Hz
PHYSICAL
Connection type
Euroblock input connector
Power type selector
Rear panel selector
Installation options
Concealed in false ceilings or partition walls, on walls' surface, etc
Enclosure material
Wooden - TBC
Mounting system
Cabinet
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
<90% HR
Included accessories
Coupling pipe for false ceiling and grill, installation accessories included
Finished colour
Black (RAL 9005)
Dimensions
200 x 200 x 320 mm / 7.9 x 7.9 x 12.6 in. (WxHxD)
Weight
6.5 kg / 14.3 lb
Pieces per box
Unit
Shipping dimensions
360 x 260 x 400 mm / 14.17 x 10.24 x 15.75 in. (WxHxD)
Shipping weight
8.9 kg / 19.62 lb
