Screen size (diagonal)
46"
Native resolution
1920 x 1080 (16:9)
Technology
Commercial-grade LCD
Backlight
Direct LED
Pixel pitch
0.53 x 0.53mm
Display orientation
Landscape or portrait
Nominal bezel size
2.0mm (bottom/right)
3.4mm (top/left)
Brightness
700 nits (cd/m2) maximum
500 nits (cd/m2) typical
Contrast ratio
(full field) 4000:1
Viewing angle (CR 10:1)
178° h/v
Refresh rate
50/60 Hz
Response time
6.5 ms
LED lifespan (50% brightness)
50,000 hrs
Peak white color temperature
10,000 K
Colour space
(CIE 1931) 72%
Display colours
1.07 billion
Signal inputs
Display Port
HDMI (HDCP) x 2
DVI (HDCP)
Component
VGA
S-Video
Composite
Audio L/R
Audio 3.5mm
Infrared extender 3.5mm
Signal outputs

DVI (HDCP)
VGA
Audio 3.5mm
Control inputs
RS-232, RS-485
Control outputs
RS-485
Power supply
100-240V AC @ 50/60Hz; 2A
Panel power consumption
170W maximum
105W typical
<=0.5W standby
ENERGY STAR®
6.0
Operating temperature
41 - 104°F (5 - 40°C)
Operating humidity
20-90% non-condensing
Storage temperature
-4 - 41°F (-20 - 60°C)
Panel only dimensions
(WxHxD) 40.31 x 22.77 x 3.08"
(1023.8 x 578.4 x 78.2)
Panel with quick access mount1
(WxHxD) 40.31 x 22.77 x 6.15-6.90"
(1023.8 x 578.4 x 156.2-175.2mm)
Panel with thin profile mount1
(WxHxD) 40.31 x 22.77 x 3.78"
(1023.8 x 578.4 x 95.7mm)
Panel only weight
51lbs (23Kg)
Panel and quick access mount weight
99lbs (45Kg)
Panel and thin profile mount weight
64lbs (29Kg)
Panel mount locations
VESA standard (WxH) 600mm x 400mm
Runtime
Designed for 24/7 operation2, featuring a reliable power supply and cooling system
Features
Commercial grade LCD; anti-glare coating; full HD resolution; landscape or portrait orientations; front-accessible mount; stackable frames and pedestals; advanced cooling design; high energy efficiency with <=0.5W standby; Plug and Play (DDC2B); bezel compensation option; Image Retention Frame Motion (IRFM) mode; Auto Scan source selection; aspect-ratio control; zoom; Picture-in-Picture (PiP); advanced image settings; configurable power on delay; sleep timer; single DVI input can be shared by up to 3x3 panels; control up to 25 panels through single RS-232 and Video Wall Toolbox software on a remote PC; auto setup for single-input video wall; control each panel with on-screen display (OSD) using infrared (IR) remote control.
Accessories
Panel ships with remote control with IR extender, DVI cable, Ethernet cable (RS-485), RS-232 cable; regional power cord available separately
Quick access wall mounts: ML10 for landscape, MP10 for portrait, spacer kit available
Thin wall mount available from third party
Regulatory
Conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):

Directives: (EC) 2011/65/EU(RoHS) • 2012/19/EU (WEEE)
Regulations: (EC) No. 1907/2006 (REACH)
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1 / EN 60950-1
FCC, Part 15, Subpart B, Class A • ICES/NMB003 (A) • EN55022/CISPR22 Class A • EN55024/CISPR24
Designed to comply to the rules and regulations required for the product to be sold in various regional markets, including: USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, Russia, India, Singapore, Brazil, UAE, South Africa, and Saudi Arabia

Warranty
Three years parts and labour limited warranty
Contact an authorised Christie representative for full details of our limited warranty
