Pixel pitch
3.0mm
Pixel configuration
3-in-1 (1R1G1B)
​Pixel density
​111,111 pixels/m2
Maximum calibrated brightness
800 nits (cd/m2)
​Aspect ratio
​1:1
Contrast ratio (full field)
5000:1
Viewing angle
160° H, 140° V
Refresh rate​
>3200Hz
​Scan rate
​​1/16​
Colour​ temperature
2700-9300K
​Display colours
281 trillion
Inputs
HDMI (HDCP), DVI (HDCP)
Input rating
100-240 VAC @ 50/60Hz
Power consumption
per cabinet
37W typical
110W maximum
​Heat output
​101 BTU/hr typical
300 BTU/hr maximum
Operating temperature
32-104°F (0-40°C)
Operating humidity
10-90% non-condensing
Storage temperature
14-131°F (-10-55°C)
IP rating

30
Environment
Indoor
LED lifespan
(50% brightness)
100,000 hrs
Runtime
24/7
Tile dimensions
(WxHxD) 18.9 x 18.9 x 3.39" (480 x 480 x 86.04mm)
​Tile area
​2.48 ft2 (0.2304 m2)
Tile resolution
160 x 160
Tile weight
23.4lbs (11.5kg)
Cabinet design
Die-cast aluminium
Service access
Front and rear service only
Module dimensions
(WxH) 9.5 x 9.5" (240.0 x 240.0mm)
Module resolution
80 x 80 pixels
​Installation options
​Flat
Hanging
Concave
​Stacking height
​20 units1
Orientation​
​360 degrees2
Certification​
​​UL60950
FCC
CE
EMC
​RoHS
RCM
Limited warranty
Three year parts and labour limited warranty
Contact an authorized Christie representative for full details
Extended warranty option available for a one-time fee at time of purchase
