Screen size (diagonal)
49" (124.4cm)
Active area 48.5" (123.2cm)
Native resolution
1920 x 1080 (16:9)
Backlight
Edge-lit LED technology
LED lifespan
50,000 hours (50% brightness)
Display orientation
Portrait
Landscape
Pixel pitch
0.559 x 0.559mm
Nominal bezel size
Even 6.5mm (13mm combined)
Brightness
500 nits (cd/m2) typical
Contrast ratio (full field)
1300:1 typical
Viewing angle (CR 10:1)
178° h/v
Refresh rate
50-85Hz
Response time
8ms
Color space (CIE 1931)
72%
Display colors
10 bit
1.07 billion
Signal inputs
HDMI x 2
DisplayPort
DVI-D
VGA
Composite
Component
USB playback
Audio L/R
Audio RCA jack/phone jack
Signal outputs
DisplayPort
DVI-I
Audio speaker connector/phone jack
Control inputs
IR
RS-232
Keypad
Control outputs
RS-232
Power input rating
100-240 VAC @ 50/60Hz
Power consumption
Without OPS: 176W maximum; 120W typical
With OPS: 240W maximum; 140W typical1
≤0.5W standby
Operating temperature
32-104°F (0-40°C)
Operating humidity
20-80% RH non-condensing
Storage temperature
4-122°F (-10-55°C)
Physical size (without handle)
(WxHxD): 40.02 x 24.53 x 2.24" (1092.7 x 623.0 x 56.8mm)
Weight
41.9lbs (19 kg)
Panel mount locations
VESA (WxH) 400 x 400mm
M6 (10mm internal depth)
Runtime
Designed for 24/7 operation featuring a reliable power supply and cooling system2
Features
24/7 Commercial-grade LCD with edge-lit LED
Standard size OPS
Photo, music and video USB playback
10W x 10W speakers
Kensington lock
Auto source switching and recovery
Smart Scheduling
Bezel compensation
Carrying handles
Keyboard/RC lockout
Up to 10W x2 video wall scaling
Accessories
Panel ships with AC power cord
DisplayPort cable
RS-232 cable
Daisy chain cable for RS232 and IR
IR receiver
Remote control
User manual
Warranty
Three years parts and labor limited warranty
Contact an authorized Christie® representative for full details
