Outputs
Dual DisplayPorts: Up to 2560x1600 pixels per output
Inputs
Up to 5 video sources from 640x480 to 1920x1080 encoded to H.264
2 analog 3.5mm stereo audio
Up to 5 audio encoded streams to H.264
4 USB ports
Network
Internal 2.4GHz wireless access point
IEEE 802.11 a/b/g/n standard
2Tx / 2Rx MIMO
Up to 300 Mbps data rate
64/128/152 bit WEP, WPA, WPA2, 802.1x, AES & TKIP
Decoding
Up to 5 high-definition network video streams @ 30Hz
Protocols supported
AirPlay
MS Network Projector
Brio Screen Projector (for use with Android devices)
Physical Specifications
Size: (WxHxD) 8" x 1.9" x 8.9" (204 x 49 x 252mm)
Weight: 2.8 lbs (1.27kg)
Power
Voltage range: 100-240V AC (auto-ranging power supply)
Current: 2A
Power consumption: 120W (max)
Reliability
MTBF: >50,000 hours for major modules
Regulatory
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1 emissions
FCC CFR47, Part 15, Subpart B, Class A – unintentional radiators
EN55103-1 Class A audio, video, audio-visual equipment emission; EN55103-2 audio video, audio-visual equipment immunity; EN61000-3-2, EN61000-3-3
Directives: (EC) 2011/65/EU (RoHS); 2012/19/EU (WEEE); Regulation (EC) No. 1907/2006 (REACH)
Certification marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), Saudi Arabia, South Africa, Ukraine, Mexico, GoST-R (Russia) and/or Customs Union which includes Belarus, Kazakhstan, Russia, KC (Korea), S-Mark (Japan), C-Tick (Australia & New Zealand), Taiwan
Manufacturing location
Designed, manufactured, and tested by Christie Digital Systems Inc. at our facility in Phoenix, Arizona, USA
Warranty
Limited two years parts and labour
