Outputs
Dual DisplayPorts: Up to 2560x1600 pixels per output
Inputs
Dual DVI-D: Support for up to 2560 x 1600 pixels per input (wired connection)
Up to 5 video sources from 640x480 to 1920x1080 encoded to H.264
2 analog 3.5mm stereo audio
Up to 5 audio encoded streams to H.264
Support for HDCP (High-bandwidth Digital Content Protection)
4 USB ports
Network
Gigabit Ethernet 1000 Mbps Ethernet, RJ45 connector
Support for IGMPv2, IPv4, RTSP, SRTP, HTTP, TCP/IP
Encoding
2 high definition DVI-D inputs to L5 H.264 video streams @ 30 FPS
Up to 5 high-definition L5 H.264 video streams @30 FPS
2 stereo audio streams
Support for variable bitrate
Decoding
Up to 5 high-definition network video streams @ 30Hz
Protocols supported
Airplay
MS Network Projector
Brio Screen Projector (for use with Android devices)
Physical Specifications
Size: (WxHxD) 17.40" x 1.74" x 9.5" (442 x 44 x 241mm)
Weight: 6.5lbs (2.95kg)
Chassis: 1U form factor
Mounting: Mounting brackets (ears), optional under table mount, optional VESA "sandwich" mount
Power
Voltage range: 100-240V AC (auto-ranging power supply)
Current: 2-4A (max)
Power consumption: 220W (max)
Reliability
MTBF: >50,000 hours for major modules
Regulatory
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1 emissions
FCC CFR47, Part 15, Subpart B, Class A – unintentional radiators
EN55103-1 Class A audio, video, audio-visual equipment emission; EN55103-2 audio video, audio-visual equipment immunity; EN61000-3-2, EN61000-3-3
Directives: (EC) 2011/65/EU (RoHS); 2012/19/EU (WEEE); Regulation (EC) No. 1907/2006 (REACH)
Certification marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), Saudi Arabia, South Africa, Ukraine, Mexico, GoST-R (Russia) and/or Customs Union which includes Belarus, Kazakhstan, Russia, KC (Korea), S-Mark (Japan), C-Tick (Australia & New Zealand), Taiwan
Manufacturing location
Designed, manufactured, and tested by Christie Digital Systems Inc. at our facility in Phoenix, Arizona, USA
Warranty
Limited two years parts and labour
