600 lumens ANSI ±10% (rated at 75-80% EBU depending on the lens)
10,000:1 dynamic, 1,400:1 FOFO, 450:1 ANSI.
95% brightness and colour uniformity after electronic adjustment
Display Technology and Resolution
Revolutionary solid state projector using a single TI Darkchip 3™ DMD with a solid state illumination engine (no colour wheel) and sealed optics
Native 1920 x 1200 (16:10 aspect ratio) WUXGA
Input
signals: Up to 1920 x 1200 WUXGA (Native 1920 x 1200 recommended)
pixel clock: 330MHz max input
scan rates: Horizontal: 15-150KHz • Vertical: 23.97-120Hz
Inputs, Control & Networking
RS232 in/out
RS422 in
Ethernet (10/100)
USB device
GPIO (RS232 9-pin male connector)
Dual 7 segment status display
Remote control (with optional wired XLR connection)
Slot 1-2 standard (populated): two Dual link DVI-D (330MHz) input cards. Each has a VGA (165MHz) port
Slots 3-4 unpopulated
Full bandwidth Analog BNC
Dual Link DVI input card (330MHz), VGA (165MHz)
Dual SD/HD-SDI
Video Decoder*
Twin HDMI
Two standard Dual Link DVI input cards (330MHz)
*The Dual link DVI input card has a 330MHz DVI-I connector which can support a single or dual-link DVI, analog and HDCP video signals with proper cables. There is also an additional 15-pin VGA connector for signals under 165MHz. Only one input is active on this card at a time. Two of these cards come standard on the Christie Mirage WU-L
Optical system
Lens mount

Mechanical, horizontal and vertical lens shift
No shutter required
No iris required – user programmable illumination parameters (eliminates the need for a mechanical shutter)
Illumination

Full spectrum LED (RGB)
Illumination package has a MTBF of 60,000 hrs
Light module can be changed in 15 minutes and is color and bright level matching in real-time to the projector array
Christie ArrayLOC™

Manages the brightness and colour levels of all projectors within an array to a common level, in real-time with no additional latency
Lenses* - standard or optional
Fixed

0.64:1 WUXGA lens
0.75:1 WUXGA lens
Zoom

1.2-1.6:1 WUXGA lens
Offsets

0.64:1 lens features ±5% (horizontal) and ±5% (vertical) offset when mounted in landscape orientation
0.75:1 lens features ±80% (horizontal) and ±100% (vertical) offset when mounted in landscape orientation
1.2-1.6:1 lens features ±80% (horizontal) and ±100% (vertical) offset when mounted in landscape orientation
*Each offset is specified with the other at zero. Simultaneous horizontal and vertical offsets may limit the adjustment range of each.

Standard accessories
User manual
IR remote with hard wired cord
Line cord
Two Dual Link DVI-D Cards
3D sync cable
Optional accessories
Analog RGBHV BNC input card for Analog sources greater than 165MHz
Dual link DVI input card*
Dual HD-SDI input card
Twin HDMI input card
User kit (includes manual, IR remote and hard wired cable for the remote)
Rugged Motion Platform user kit (purpose-built) avaialble
Enhanced feature sets
Minimum Processing Latency (MPL™)
Christie Twist™ II – advanced warping/edge-blending hardware technology integrated directly into the projector, includes warping/blending software
Auto setup, power up
Menus in 8 languages Multiple channel memories (for recall memory storage)
Christie ArrayLOC™ – automatic, continuous management of brightness and colour space levels of all projectors in an array to a common level, in real-time
Power requirements
operating voltage: 100-240V AC 50/60Hz
operating current: 5.3A
dissipation: 1364 BTU/hr (variable, dependent on content)
Dimensions
Size:

Projector head module + light module (no lens): 8.7 x 18.4 x 11.0" (220 x 467 x 287mm)
Electronics module: 16.5 x 5.5 x 6.7" (420 x 140 x 170mm)
Weight

Projector head module + light module (no lens): 32lb (14.6kg)
Electronics module: 9.7lbs (4.4kg)
Shipping weight:

52lb (23.6kg)

Operating Environment
Noise: 38dBA at 25°C ambient temperature (without electronics module)
Operating temperature: 40-95ºF (5-35ºC)
Humidity: 20-80% non-condensing
Regulatory Approvals
Directives (EC) 2002/95/EC (RoHS)
2002/96/EC (WEEE)
Regulation (EC) No. 1907/2006 (REACH)
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1
FCC, Part 15, Subpart B, Class A
EN55022/CISPR22 Class A
EN55024 / CISPR24
Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC/KCC (Korea), PSE (Japan), C-Tick (Australia & New Zealand)
Warranty
2 years parts and labour (inclusive)
Contact an authorised Christie representative for full details of our limited warranty
