Image Brightness
35,000 centre (32,500 ANSI) lumens – 6.0kW Lamp
29,000 centre (27,000 ANSI) lumens – 4.5kW Lamp
19,500 centre (18,000 ANSI) lumens – 3.0kW Lamp
13,000 centre (12,000 ANSI) lumens – 2.0kW Lamp
Contrast Ratio
2000:1 (full on/off)
Uniformity
90% brightness uniformity
Display Type
3-chip 1.25" DMD
Native Resolution
DC2K (2048 x 1080)
Lamp Type
Xenon bubble (user-replaceable bulb)
Typical Lamp Lifetime
6.0kW 1000 hrs (750 hrs at 6.6kW)
4.5kW 900 hrs
3.0kW 2500 hrs
2.0kW 3500 hrs
Signals
HDTV formats
VGA through to QXGA (2048 x 1536)
Accepts all current HDTV/DTV formats
Multi-standard video decoder
Horizontal and vertical scaling, all inputs
Pixel Clock
210MHz
Scan Rates
Horizontal: 15kHz to 120kHz
Vertical: 23.97Hz to 150Hz
Inputs, Control and Networking
RGBHV/YPbPr: 5 BNC
DVI-I Analog / Digital RGB/YPbPR (HDCP)
S-video
Composite video
2 RS-232 ports
RS-422 ports
GPIO port
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in backlit LCD keypad
Front and rear IR receivers
2 input slots for analog/digital modules
Standard Accessories
Dual SD/HD-SDI input card
Detached 7kW switching lamp ballast
IR Remote keypad (with optional wired connection)
Line cord
6ft ballast cable
Handles for carrying and rigging
User manual
Optional Accessories
Input cards – DVI, Dual SD/HD-SDI
Christie Twist™
Remote IR sensor
Wired remote control
Rigging frame (required for portrait mode)
Rigging clamps
Lamp safety kit
High-contrast aperture kits
6ft, 25ft, 50ft or 100ft ballast cable kit
Service manuals
KoRE 10-bit librarian software
Filter replacement packs
Portrait upgrade kit for existing Christie Roadie HD+35K models
Lens Mount Type
Tool-free lens insertion system
Boresight adjustable
Motorized Lens Mount
Horizontal and vertical offset
Focus
Zoom
Lens Options
0.8:1 Fixed Lens (offset: ±45% V, ±15% H)
1.1:1 Fixed Lens (offset: ±74%V, ±21% H)
1.25-1.45:1 Zoom Lens (offset: ±100% V, ±35% H)
1.45-1.8:1 Zoom Lens (offset: ±53% V, ±17% H)
1.8-2.4:1 Zoom Lens (offset: ±53% V, ±17% H)
2.2-3.0:1 Zoom Lens (offset: ±53% V, ±17% H)
3.0-4.3:1 Zoom Lens (offset: ±53% V, ±17% H)
4.3-6.0:1 Zoom Lens (offset: ±53% V, ±17% H)
5.5-8.5:1 Zoom Lens (offset: ±100% V, ±35% H)
Projector Head Power Requirements
Operating voltage: single phase 200-240V AC @50/60Hz
Max current: 3A max
Ballast Power Requirements
Type: detached 7kW switching lamp ballast
Operating voltage: 3-phase 200-230V AC @50/60Hz
Max current: 24A per phase max
Operating voltage: 3-phase 380-415V AC @50/60Hz
Max current: 16A per phase max
Projector Head Dimensions
(L x W x H): 53.6 x 31.5 x 22.8" (1362 x 800 x 577mm)
Shipping dimensions (L x W x H): 65 x 41 x 35" (1650 x 1040 x 890mm)
Weight 360lb (163kg)
Shipping weight 460lb (209kg)
Ballast Dimensions
(L x W x H): 21 x 18 x 21" (533 x 457 x 533mm)
Shipping dimensions (L x W x H): 28 x 25 x 31.5" (710 x 635 x 800mm)
Weight 110lb (50kg)
Shipping weight 145lb (66kg)
Optional rigging frame dimensions
(L x W x H): 59.4 x 33.5 x 25.7" (1510 x 851 x 653mm)
Shipping dimensions (L x W x H): 54 x 32 x 10" (1372 x 813 x 254mm)
Weight 110lb (50kg)
Shipping weight 166lb (75kg)
Operating Environment
Temperature: 5 to 35° C (40 to 95° F)
Humidity: 20 – 80% non-condensing
Regulatory
UL/CSA/IEC 60950 (3rd edition)
FCC Class A, CE
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, WEEE
Limited warranty
3 years parts and labour (including light engine)
Contact an authorised Christie representative for full details of our limited warranty
