Specyfikacja techniczna:


Brightness: 7,650 ISO lumens, 6800 ANSI, 6800 Center
Dynamic c​ontrast: 65,000:1
Colors: 1.074 billion
Display technology

3 x inorganic LCD 0.74" Polysilicon TFT active matrix
1920 x 1080 (2,073,600 pixels)
16:9
Lamp

430W UHP lamp
Standard mode: up to 3,000 hours
Eco mode: up to 4,000 hours
Portrait mode: up to 1,000 hours
Inputs

HDMI x 2
DisplayPort x 1
HDBaseT x 1
D-sub 15 pin (RGB and Component) x 1
Composite video x 1
USB type A connector x 1 (for wireless USB dongle)
3G-SDI x 1
Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock

25.2 ~ 162 MHz
Outputs, control and networking

Monitor out D-sub 15 pin (RGB) x 1
Audio ​out port
D-sub 9 pin x 1 (RS232c)
HDBaseT (X1*used in standard inputs)
RJ45 Ethernet (10/100)
Wired Remote Jack (3.5stereo mini) x 1
Lenses

UST lens (121-128102-01)
Fixed short throw lens 1.0:1/0.8:1 (121-111104-01)
Long throw zoom lens 3.6-6.1/2.8-4.9 (121-114107-01)
Middle throw zoom lens 1.7-3.0/1.7-2.9 (121-130105-01)
Short throw zoom lens 1.5-2.2:1/1.2-1.8:1 (121-129103-01)
Ultra long throw zoom lens 6.0-10.3/4.9-8.3 (121-115108-01)
Optional accessories

Replacement lamp 003‐005336‐01
Wireless adapter (USB) (121-116109-XX)
Christie One Mount (108-506102-XX)
Cable cover for white models (121‐133108‐XX)
Cable cover for black models (121‐132107‐XX)
Replacement filter: 20,000 hr (003-005339-01)
Power requirements

Operating voltage

100-120 VAC
220-240 VAC @ 50/60Hz
Consumption

580W +10% or less at 100-120 VAC
560W +10% or less at 220-240 VAC
Operating current

5.9A +10% or less at 100-120 VAC
2.9A +10% or less at 220-240 VAC
Dissipation

1,979 BTU/hr at 100-120 VAC
1,911 BTU/hr at 220-240 VAC
Dimensions (LxWxH)

Body without feet at min height

18 x 19.6 x 6.7" (456 x 498 x 170mm)
Shipping size

22.1 x 27.7 x 12.4" (561 x 703 x 314mm)
Weight

24.5 lbs (11.1kg) (without lens)
Shipping Weight

32.6 lbs (14.8kg) (without lens)
Operating environment

Noise

Standard mode: 41dBA
Eco mode: 33dBA
Temperature

Standard mode: 32-104°F (0-40°C)
Eco mode: 32-113°F (0-45°C)
Altitude

0-10,000ft (3048m)
Humidity

10-80% non-condensing
Key features

Single lamp
3G SD/HD-SDI input
Blending and warping
360° on axis capable
Camera-based, easy blend and warp with included software
Christie® QuickConnect App for projector management and collaboration available for download
Single point of connection through HDBaseT and Christie OneConnect
eClarity
Advanced Color Management
HDCR
Digital image shift technology
Up to 20,000 hour filter
ILS lens memory (lens shift and lens type only)
AMX and Crestron connectivity
Wireless capable
Built-in LCD status panel
DICOM simulation mode
Picture-in-picture / Picture-by-picture
Limited warranty

Three years parts and labor (including light engine)
Lamp: 500 hours or one year (whichever comes first)
Contact an authorized Christie representative for full details of our limited warranty
