Screen size (diagonal)
84"
Native resolution
3840 x 2160 (16:9)
Backlight
Edge-lit LED
LED lifespan
30,000 hrs (50% brightness)
Display orientation
Landscape
Pixel pitch
0.4845 x 0.4845 mm
Nominal bezel size
35 mm
Brightness
320 nits (cd/m2) typical
​430 nits (cd/m2) maximum
Contrast ratio (full field)
1000:1 typical
Viewing angle (CR 10:1)
178° h/v
Refresh rate
120Hz
Response time
12ms
Color space (CIE 1931)
72%
Display colors
10 bit
1.06 billion
Inputs
HDMI 1.4b x 4
DisplayPort 1.2
VGA
USB type A (firmware updates)
USB 2.0 type B (Touch control)
IR
OPS-HDMI 1.4b
OPS-DP 1.1a
AC
Infrared Receiver
Audio 3.5mm
6 key control buttons
Outputs
Audio 3.5mm
Control inputs
RS-232 via extension cable (included)
Power input rating
100-240 VAC @ 50/60Hz
Power consumption
Without OPS: 500W maximum; 315 typical
With OPS: 620W maximum; 330 typical
>=0.5W standby
Operating temperature
32-104°F (0-40°C)
Operating humidity
20-80% RH non-condensing
Storage temperature
4-140°F (-20-60°C)
Size
(WxHxD): 77.80 x 45.71 x 4.11" (1976 x 1161 x 104.5mm)
(D): 3.81" (96.7mm) without handle
Weight
211.6lbs (96kg)
Panel mount locations
VESA standard (WxH) 600 x 600mm
Runtime
Designed for 24/7 operation featuring a reliable power supply and cooling system1
Features
Open Pluggable Specification (OPS) slot
Commercial-grade LCD
Anti-glare coating
UHD resolution (3840 x 2160 @120Hz)
Landscape only
10 point multi-touch2
Plug and Play (DDC2B)
Motion Estimation Motion Compensation (MEMC) supported
Control with on screen display (OSD) using infrared (IR) remote control
Sleep mode
Built in 10W x 2 speakers
Multi-window options including: Dual, Quad (allowable resolution: ≤ 1080p @ 60Hz)
Accessories
Panel ships with remote control
External IR receiver
RS-232 cable
USB cable
Quick start guide and multi-language user manual CD
Warranty
Three years parts and labor limited warranty
Contact an authorized Christie representative for full details of our limited warranty
