Crossover : Linear phase, asymmetric, 2-way, passive @ 1.5kHz, 12dB/octave
Depth : 398.78 mm
Enclosure :

Closed box alignment
Heavily damped and braced

Height : 1267.46 mm
Impedance : 4 ohm
Input Connectors : Screw terminal barrier strip
Maximum SPL : 130dB (AES), 132dB (IEC) long term, 133dB (IEC) short term
Sensitivity : 103 dB
Throw Distance : 138' (42m) standard, 95' (28m) -6dBFS pink noise
Width : 269.24 mm
Width : 10.60 in
Accessories (optional) :

Christie S215 subwoofer
BKT-LA4 tilt bracket (for mounting on Christie S215)
BKL-LA4 "L" bracket (for flying under Christie S215)
Allen Products MM-120 (for wall mount)

Recommended Amplifier Power : 500 to 2000W (FTC) @ 4 ohms
Power Handling : 1500W (IEC) long term, 2000W (IEC) short term
Power Handling : 1000 Watt
System Type : Coaxial articulated ribbon driver line array, 2-way, passive, in a single sealed enclosure
Maximum SPL (Sound Pressure Level) : 141 dB
Driver Components :

8 x 6" ribbon drivers with Neodymium magnets
8 x 6.5" paper/Kevlar composite cone drivers

Coverage Horizontal : 120 degrees
Coverage Vertical : 40 degrees
Warranty (Length/Type) : 5 Years Limited
Construction : 18mm marine plywood
Speaker Diameter (Driver) : 152.40 mm
Net Weight : 44.45 kg
