Native resolution

4K UHD 3840 x 2160 (16:9)

Backlight

Edge-lit LED

LED lifespan

50,000 hours to 50% brightness

Display orientation

Landscape

Pixel pitch (WxH)

0.493 x 0.493mm

Bezel size (bottom/side/top)

14mm/12mm/12mm

Brightness (typical) - (cd/sq m)

410 nits

Contrast ratio (typical)

1,200:1

Viewing angle (CR 10:1)

178 degrees h/v

Refresh rate

60Hz

Response time (typical)

8ms

Color space typical (CIE 1931)

72% minimum

Display colors

10 bit, 1.07 billion

Video inputs

4 x HDMI (Ver 2.0, HDCP 2.2)

DisplayPort (Ver 1.2a, HDCP 1.3)

VGA

OPS

2 x USB 2.0

USB 3.0

Video outputs

DisplayPort 1.2a

HDMI 2.0

Control inputs

RS-232 (D-Sub9)

LAN (RJ45)

IR wire extender

Power consumption

251W typical without OPS

310W maximum without OPS

≤0.5W in standby without OPS

Display colors

10 bit, 1.07 billion colors

Audio inputs

RCA (L/R) line in

Audio outputs

3.5mm headphone jack

Optical Audio Out

Operating temperature

32-104°F (0-40°C)

Storage temperature

-4-140°F (-20-60°C)

Operating humidity

20-90% RH non-condensing

Physical size (panel only)

(WxHxD) 75.9 x 43.3 x 3.1" (1928 x 1099 x 80mm)

Physical weight

144.4lbs (65.5kg)

Mounting

VESA 600 x 400mm, M8

Runtime

Designed for 16/7 operation featuring a reliable power supply*

Features

Commercial LCD with LED backlight

On/off scheduler

HDR10 support

Auto source switching

Video wall mode

Low latency video processing option

Wake on LAN

On/off scheduler

USB media playback of Photo / Video /MP3

2 x 10W built-in speakers

OPS module slot

HDMI-CEC

Failover auto source switching

Kensington lock

Wi-Fi and Miracast device connectivity

Pixel Shifting

Accessories

Panel ships with IR remote control

External IR reciever

Power cable

User manual

Optional WiFi Module**

Warranty

Three years parts and labor limited warranty

* Avoid static images for extended periods. Refer to product documentation for additional guidelines.

**Wi-Fi capability is provided via optional USB dongle

Due to constant research, specifications are subject to change without notice.
