Contrast ratio Dynamic contrast ratio of up to 10,000,000:1
Resolution 4096x2400 (10 megapixel)
Brightness Up to 6,000 lumens
Brightness uniformity 85% +/- 15%
Display technology 1.2" Generation2011 LCoS
Inputs 4 x dual-link DVI inputs for up to 16bit image formats
Compatibility All current simulator formats up to 10 Mp
Input frequency Up to 330 MHz per dual-link DVI
Lamp 2 kW xenon lamp, in lamp housing, pre-aligned for max. light output. Typical lifetime in economy mode: up to 1,800h

Pro-rated lamp warranty
Optics Two-story optical engine for outstanding color uniformity
Lens Shift Vertical shift: -100% to +100%
Horizontal shift: -50% to +50% (no shift on QXD 0.80:1 lens)
Power consumption Normal operation: 3200W (Full power mode) / 2400W (Eco-mode)
Power Dissipation Below 11000 BTU (Full power mode) / 8200 BTU (Eco-mode)
AC power 195V – 250 V
Dimensions (WxLxH) 670 x 800 x 365 mm
(26 x 31 x 14 inch)
Safety Regulations Compliant with UL 1950 and EN60950
Electromagnetic Interference Complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A
