Light output (typical)
6,000 ANSI lumens (±10%)
6,300 center lumens (±10%)
Contrast (standard)
2,200:1 full field
Resolution (native)
1,920 x 1,200 pixels
Display technology
3 × DLP 0.67" DMD
Lamp power
2 × 280W UHP
Brightness uniformity (standard)
95%
Inputs
2x HDMI (HDCP 1.3)
1x YUV1 (on RCA/cinch)
1x Composite video (on RCA/cinch)
1x S-Video (on 4-pin mini-DIN)
1x RGBHV/YUV2 (on VGA/BNC)
Picture-in-picture
1 main window, 1 PiP window
Pixel clock
165 MHz
Communication ports
10/100 Mb/s Ethernet (on RJ45)
RS-232 (on D9)
IR external
2x 12V trigger
Available zoom lenses
RLD (1.45 ~ 1.74:1)
R9832742
RLD (1.74 ~ 2.17:1)
R9832743
RLD (2.17 ~ 2.90:1)
R9832744
RLD (2.90 ~ 4.34:1)
R9832745
RLD (4.34 ~ 6.76:1)
R9832746
Available fixed focal lenses
RLD (0.77:1)
R9832740
RLD (1.16:1)
R9832741
Lens shift (max)
Hor: ±30% - Vert: ±100%
AC power
100 - 240 VAC (±10%)/50-60 Hz
Power consumption
700 W (at 240V)
Operating temperature
0 ~ 40°C
Noise level
Normal operation: 37 dB - Eco mode: 32 dB
Weight
26 kg (57.3 lbs)
Dimensions (H x W x L)
247 x 516.7 x 669.74 mm (9.72" x 20.34" x 26.37")
Warranty
2 years standard, 1 year extendable
Order info:
RLM-W6 (body only)
RLM-W6 (incl. lens)
Rental Pack
CAV Pack
RLM-W6
Extended Warranty
RLM-W6 Priority Service
R9006300
R9006301B1
R9006302B2
(
2x RLM-W6 w/lens + stacking frame + 2 spare lamps)
R9006303B1
(
RLM-W6 w/lens + ceiling mount kit + 2 spare lamps)
R9899702
R9899703
