Projector type WUXGA three-chip DLP projector
Technology 0.67" DMD x 3
Resolution 1,920 x 1,200 WUXGA
Brightness 8,300 ANSI lumens*
5,800 ANSI lumens (eco-mode)*
*Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
Contrast ratio 1,800:1
Brightness uniformity 85%
Aspect Ratio 16:10
Lens type RLD lens
Lenses 0.77:1; 1.16:1; 1.45-1.74:1; 1.74-2.17:1; 2.17-2.9:1; 2.9-4.34:1; 4.34-6.76:1
Optical lens shift Vertical: -100% to +100% / horizontal: -30% to +30%
Color correction P7
Lamps 350W x 2 NSH
Lamp lifetime Preliminary: up to 1,500 hours (full power) / Up to 2,500 hours (eco mode)
Transport with lamp Yes
Sealed DLP™ core Sealed gap between DMD and prism
Optical dowser Yes
Advance Picture in Picture Up to two sources simultaneously
Orientation table - ceiling
Keystone correction Yes
Inputs 5 BNC, VGA, HDMI-1, HDMI-2
Input Resolutions up to WUXGA (1,920 x 1,200) 60Hz
Software tools Projector Toolset
Control IR, RS232, RJ45
Network connection 10/100 base-T, RJ-45 connection
Power requirements 100-240V / 50-60Hz
Max. power consumption 890~910W @ 110 VAC / 855~875W @220 VAC / less than 2W (standby)
Noise level (typical at 25°C/77°F) 43 dBA (bright mode) / 38 dBA (eco mode)
Operational ambient temperature 0-40°C / 32°-104°F
Operational humidity 0-90%
Dimensions (WxLxH) 670 x 530 x 265mm
Weight 32.5 kg
Shipping dimensions (WxLxH) 829 x 709 x 437mm
Shipping Weight from Factory 45 kg
Certifications CB test certificate, US emc, US safety, CE emc and safety, CCC emc and safety
Warranty 3 years standard warranty**
**Warranty and service conditions can differ from region to region. Contact your local sales or service rep for more details
