Brightness 11,500 lumens (typical)
Native contrast ratio 5,000:1 / 600:1 native ANSI contrast
Prime lenses 1.13-1.72; 1.35-1.86; 1.46-2.10; 1.65-2.60; 2.00-3.35
Resolution 4,096 x 2,160
Long-term brightness stability 30,000 hrs @ average usage conditions
Dimensions (WxLxH) Projector: 754 x 1,129 x 604 mm / 29.69 x 44.5 x 23.78 inches
Cooler: 561.5 x 738.5 x 348 mm / 22.11 x 29.07 x 13.7 inches
Weight Projector: 144kg (318 lb)
Cooler: 32kg (70.6 lb)
Cooling liquid hose length 4 hoses; 0.5m, 2.5m, 5m and 8m (1.6ft/8.2ft/16.4ft/26.2 ft)
Vertical separation between cooler and projector Maximum 3m (10ft) (higher or lower)
Power requirements Projector: single phase 200-240V 20A
Cooler: obtains power from the projector
Heat load (max. power) 10796 BTU/h
Ambient temperature 35°C (95°F) Max. (projector and cooler)
Ambient humidity 85% Max. (projector and cooler)
Media server Barco Alchemy ICMP and other IMB brands supported.
Power consumption Projector (incl. cooler): 3.3 kW
Noise Level dB(A) @ 1 m:
67.6 dB(A)
62 dB(A) (half fan speed)
3D systems Active glasses systems and polarization systems on silver sceens are supported. Color separation systems (Dolby3D and 6P) are not supported.
Safety requirements Class 1 risk group 3
Show safety: the customer shall take precaution for the laser safety (respect the hazard distance and separation height) according to local laser show safety regulations.
Workplace safety: the customer shall take precaution for:
workplace safety as prescribed by the local authorities
basic laser safety training for operators
laser safety program implementation in the company;
access limitation only to trained personnel: area labelling, etc.
