Strona głównaPROJEKTORY MULTIMEDIALNEBARCOCoronis Fusion 6MP LED MDCC-6330
Barco

Coronis Fusion 6MP LED MDCC-6330

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Coronis Fusion 6MP LED MDCC-6330

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu
Screen technology TFT AM Color LCD Dual Domain IPS-Pro
Active screen size (diagonal) 772 mm (30.4")
Active screen size (H x V) 654 x 409 mm (25.8 x 16.1")
Aspect ratio (H:V) 16:10
Resolution Native 6MP (3280 x 2048)
Configurable to 2 x 3MP+ (1640 X 2048)
Configurable to 2 x 3MP (1536 X 2048)
Pixel pitch 0.1995 mm
Color imaging Yes
Gray imaging Yes
Color support 30 bit
Viewing angle (H, V) 178°
Uniform Luminance Technology (ULT) Yes
Per Pixel Uniformity (PPU-LED)

Yes (color PPU)
Ambient Light Compensation (ALC) Yes
Backlight Output Stabilization (BLOS) Yes (2x)
I-Guard Yes
Maximum luminance 720 cd/m²
DICOM calibrated luminance (ULT off) 500 cd/m²
Contrast ratio (dark reading room, typical) 1000:1 (panel typical)
Response time (Tr + Tf) 18 ms
Housing color Black / silver
Video input signals DVI-D Dual Link (2x), DisplayPort (2x)
Video inout terminals NA
USB ports 1 upstream (endpoint), 3 downstream
USB standard 2.0
Power requirements (nominal) 100-240V
Power consumption (nominal)

100W
Power save mode

Yes (less than 0.5W)
Power management DVI-DMPM, DP-DMPM
OSD languages English, German, French, Dutch, Spanish, Italian, Portuguese, Polish, Russian, Swedish, Chinese (simplified), Japanese, Korean, Arabic
Dimensions with stand (W x H x D) Portrait: NA

Landscape: 730 x 580~675 x 261 mm
Dimensions w/o stand (W x H x D) Portrait: NA

Landscape: 730 x 485 x 125 mm
Dimensions packaged (W x H x D) 860 x 760 x 390 mm
Net weight with stand

20.5 kg
Net weight w/o stand

14 kg
Net weight packaged with stand 29.5 kg
Net weight packaged w/o stand NA
Height adjustment range 96 mm
Tilt -5° / +25°
Swivel -30° / +30°
Pivot NA
Mounting standard VESA (100 mm)
Screen protection Protective, non-reflective glass cover
Recommended modalities

CT, MR, US, DR, CR, NM, PET
Certifications CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product), CE - 2004/108/EC, IEC 60950-1:2005 + A1:2009, EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013, IEC 60601-1:2005, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A2:2010, CAN/CSA C22.2 No. 60601-1 (2008), EN 60601-1:2006 + A11:2011, EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 + GB17625.1-2012, KCC, VCCI, FCC class B, ICES-001 Level B, FDA 510(k), RoHS
Supplied accessories User Guide
Quick Install Sheet
Documentation CD
System CD
Video cables (2 x DVI Dual Link, 2 x DisplayPort)
Mains cables (UK, European (CEBEC/KEMA), USA (UL/CSA; adaptor plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
External power supply
Optional accessories Graphics board
QA software MediCal QAWeb
Units per pallet NA
Pallet dimensions (W x H) NA
Warranty 5 years
Operating temperature 0°C to 35°C (15°C to 30°C within specs)
Storage temperature -20°C to 60°C
Operating humidity 8% - 80% (non-condensing)
Storage humidity 5% - 93% (non-condensing)
Operating altitude 3000 m
